vtkCompositePolyDataMapper Class Reference

a class that renders hierarchical polygonal data More...

#include <vtkCompositePolyDataMapper.h>

Inheritance diagram for vtkCompositePolyDataMapper:
[legend]
Collaboration diagram for vtkCompositePolyDataMapper:
[legend]

Public Types

typedef vtkPolyDataMapper Superclass

- Public Types inherited from vtkPolyDataMapper
enum  ShiftScaleMethodType {
  DISABLE_SHIFT_SCALE , AUTO_SHIFT_SCALE , ALWAYS_AUTO_SHIFT_SCALE , MANUAL_SHIFT_SCALE ,
  AUTO_SHIFT , NEAR_PLANE_SHIFT_SCALE , FOCAL_POINT_SHIFT_SCALE
}
 Methods for VBO coordinate shift+scale-computation. More...

typedef vtkMapper Superclass

using MapperHashType = std::uintptr_t

- Public Types inherited from vtkMapper
typedef vtkAbstractMapper3D Superclass

- Public Types inherited from vtkAbstractMapper3D
typedef vtkAbstractMapper Superclass

- Public Types inherited from vtkAbstractMapper
typedef vtkAlgorithm Superclass

- Public Types inherited from vtkAlgorithm
enum  DesiredOutputPrecision { SINGLE_PRECISION , DOUBLE_PRECISION , DEFAULT_PRECISION }
 Values used for setting the desired output precision for various algorithms. More...

typedef vtkObject Superclass


Public Member Functions

virtual vtkTypeBool IsA (const char *type)
 Return 1 if this class is the same type of (or a subclass of) the named class. More...

vtkCompositePolyDataMapperNewInstance () const

void PrintSelf (ostream &os, vtkIndent indent) override
 Methods invoked by print to print information about the object including superclasses. More...

void Render (vtkRenderer *renderer, vtkActor *actor) override
 Standard method for rendering a mapper. More...

void ShallowCopy (vtkAbstractMapper *mapper) override
 Make a shallow copy of this mapper. More...

void ReleaseGraphicsResources (vtkWindow *) override
 Release the underlying resources associated with this mapper. More...

std::vector< vtkPolyData * > GetRenderedList ()
 Accessor to the ordered list of PolyData that we last drew. More...

void ProcessSelectorPixelBuffers (vtkHardwareSelector *sel, std::vector< unsigned int > &pixeloffsets, vtkProp *prop) override
 allows a mapper to update a selections color buffers Called from a prop which in turn is called from the selector More...

void SetVBOShiftScaleMethod (int method) override
 A convenience method for enabling/disabling the VBO's shift+scale transform. More...

void SetPauseShiftScale (bool pauseShiftScale) override
 Pause updates of shift-scale parameters based on camera position. More...

vtkMTimeType GetMTime () override
 Overridden to include vtkCompositeDataDisplayAttributes' mtime. More...

double * GetBounds () override
 Standard vtkProp method to get 3D bounds of a 3D prop. More...

void GetBounds (double bounds[6]) override
 Standard vtkProp method to get 3D bounds of a 3D prop. More...

bool HasOpaqueGeometry () override
 Some introspection on the type of data the mapper will render used by props to determine if they should invoke the mapper on a specific rendering pass. More...

bool HasTranslucentPolygonalGeometry () override
 Some introspection on the type of data the mapper will render used by props to determine if they should invoke the mapper on a specific rendering pass. More...

void SetCompositeDataDisplayAttributes (vtkCompositeDataDisplayAttributes *attributes)
 Set/get the composite data set attributes. More...

vtkCompositeDataDisplayAttributesGetCompositeDataDisplayAttributes ()
 Set/get the composite data set attributes. More...

void SetBlockVisibility (unsigned int index, bool visible)
 Set/get the visibility for a block given its flat index. More...

bool GetBlockVisibility (unsigned int index)
 Set/get the visibility for a block given its flat index. More...

void RemoveBlockVisibility (unsigned int index)
 Set/get the visibility for a block given its flat index. More...

void RemoveBlockVisibilities ()
 Set/get the visibility for a block given its flat index. More...

void SetBlockColor (unsigned int index, const double color[3])
 Set/get the color for a block given its flat index. More...

void SetBlockColor (unsigned int index, double r, double g, double b)
 Set/get the color for a block given its flat index. More...

double * GetBlockColor (unsigned int index)
 Set/get the color for a block given its flat index. More...

void GetBlockColor (unsigned int index, double color[3])
 Set/get the color for a block given its flat index. More...

void RemoveBlockColor (unsigned int index)
 Set/get the color for a block given its flat index. More...

void RemoveBlockColors ()
 Set/get the color for a block given its flat index. More...

void SetBlockOpacity (unsigned int index, double opacity)
 Set/get the opacity for a block given its flat index. More...

double GetBlockOpacity (unsigned int index)
 Set/get the opacity for a block given its flat index. More...

void RemoveBlockOpacity (unsigned int index)
 Set/get the opacity for a block given its flat index. More...

void RemoveBlockOpacities ()
 Set/get the opacity for a block given its flat index. More...

void SetBlockScalarMode (unsigned int index, int value)

int GetBlockScalarMode (unsigned int index)

void RemoveBlockScalarMode (unsigned int index)

void RemoveBlockScalarModes ()

void SetBlockArrayAccessMode (unsigned int index, int value)

int GetBlockArrayAccessMode (unsigned int index)

void RemoveBlockArrayAccessMode (unsigned int index)

void RemoveBlockArrayAccessModes ()

void SetBlockArrayComponent (unsigned int index, int value)

int GetBlockArrayComponent (unsigned int index)

void RemoveBlockArrayComponent (unsigned int index)

void RemoveBlockArrayComponents ()

void SetBlockArrayId (unsigned int index, int value)

int GetBlockArrayId (unsigned int index)

void RemoveBlockArrayId (unsigned int index)

void RemoveBlockArrayIds ()

void SetBlockArrayName (unsigned int index, const std::string &value)

std::string GetBlockArrayName (unsigned int index)

void RemoveBlockArrayName (unsigned int index)

void RemoveBlockArrayNames ()

void SetBlockFieldDataTupleId (unsigned int index, vtkIdType value)

vtkIdType GetBlockFieldDataTupleId (unsigned int index)

void RemoveBlockFieldDataTupleId (unsigned int index)

void RemoveBlockFieldDataTupleIds ()

virtual void SetColorMissingArraysWithNanColor (bool)
 If the current 'color by' array is missing on some datasets, color these dataset by the LookupTable's NaN color, if the lookup table supports it. More...

virtual bool GetColorMissingArraysWithNanColor ()
 If the current 'color by' array is missing on some datasets, color these dataset by the LookupTable's NaN color, if the lookup table supports it. More...

virtual void ColorMissingArraysWithNanColorOn ()
 If the current 'color by' array is missing on some datasets, color these dataset by the LookupTable's NaN color, if the lookup table supports it. More...

virtual void ColorMissingArraysWithNanColorOff ()
 If the current 'color by' array is missing on some datasets, color these dataset by the LookupTable's NaN color, if the lookup table supports it. More...

void SetInputArrayToProcess (int idx, int port, int connection, int fieldAssociation, const char *name) override
 Call SetInputArrayToProcess on helpers. More...

void SetInputArrayToProcess (int idx, int port, int connection, int fieldAssociation, int fieldAttributeType) override
 Call SetInputArrayToProcess on helpers. More...

void SetInputArrayToProcess (int idx, vtkInformation *info) override
 Call SetInputArrayToProcess on helpers. More...

virtual void SetInputArrayToProcess (int idx, int port, int connection, int fieldAssociation, const char *name)
 Call SetInputArrayToProcess on helpers. More...

virtual void SetInputArrayToProcess (int idx, int port, int connection, int fieldAssociation, int fieldAttributeType)
 Call SetInputArrayToProcess on helpers. More...

virtual void SetInputArrayToProcess (int idx, vtkInformation *info)
 Call SetInputArrayToProcess on helpers. More...

virtual void SetInputArrayToProcess (int idx, int port, int connection, const char *fieldAssociation, const char *attributeTypeorName)
 Call SetInputArrayToProcess on helpers. More...

virtual void SetPointIdArrayName (const char *)
 By default, this class uses the dataset's point and cell ids during rendering. More...

virtual char * GetPointIdArrayName ()
 By default, this class uses the dataset's point and cell ids during rendering. More...

virtual void SetCellIdArrayName (const char *)
 By default, this class uses the dataset's point and cell ids during rendering. More...

virtual char * GetCellIdArrayName ()
 By default, this class uses the dataset's point and cell ids during rendering. More...

virtual void SetProcessIdArrayName (const char *)
 If this class should override the process id using a data-array, set this variable to the name of the array to use. More...

virtual char * GetProcessIdArrayName ()
 If this class should override the process id using a data-array, set this variable to the name of the array to use. More...

virtual void SetCompositeIdArrayName (const char *)
 Generally, this class can render the composite id when iterating over composite datasets. More...

virtual char * GetCompositeIdArrayName ()
 Generally, this class can render the composite id when iterating over composite datasets. More...

- Public Member Functions inherited from vtkPolyDataMapper
vtkPolyDataMapperNewInstance () const

void PrintSelf (ostream &os, vtkIndent indent) override
 Methods invoked by print to print information about the object including superclasses. More...

virtual void RenderPiece (vtkRenderer *, vtkActor *)
 Implemented by sub classes. More...

void Render (vtkRenderer *ren, vtkActor *act) override
 This calls RenderPiece (in a for loop if streaming is necessary). More...

double * GetBounds () override
 Return bounding box (array of six doubles) of data expressed as (xmin,xmax, ymin,ymax, zmin,zmax). More...

void GetBounds (double bounds[6]) override
 Get the bounds for this mapper as (Xmin,Xmax,Ymin,Ymax,Zmin,Zmax). More...

void ShallowCopy (vtkAbstractMapper *m) override
 Make a shallow copy of this mapper. More...

virtual void MapDataArrayToVertexAttribute (const char *vertexAttributeName, const char *dataArrayName, int fieldAssociation, int componentno=-1)
 Select a data array from the point/cell data and map it to a generic vertex attribute. More...

virtual void MapDataArrayToMultiTextureAttribute (const char *textureName, const char *dataArrayName, int fieldAssociation, int componentno=-1)

virtual void RemoveVertexAttributeMapping (const char *vertexAttributeName)
 Remove a vertex attribute mapping. More...

virtual void RemoveAllVertexAttributeMappings ()
 Remove all vertex attributes. More...

vtkTypeBool ProcessRequest (vtkInformation *, vtkInformationVector **, vtkInformationVector *) override
 see vtkAlgorithm for details More...

virtual int GetVBOShiftScaleMethod ()

virtual bool GetPauseShiftScale ()

virtual void PauseShiftScaleOn ()

virtual void PauseShiftScaleOff ()

void SetInputData (vtkPolyData *in)
 Specify the input data to map. More...

vtkPolyDataGetInput ()
 Specify the input data to map. More...

void Update (int port) override
 Bring this algorithm's outputs up-to-date. More...

void Update () override
 Bring this algorithm's outputs up-to-date. More...

vtkTypeBool Update (int port, vtkInformationVector *requests) override
 Bring this algorithm's outputs up-to-date. More...

vtkTypeBool Update (vtkInformation *requests) override
 Bring this algorithm's outputs up-to-date. More...

virtual void SetPiece (int)
 If you want only a part of the data, specify by setting the piece. More...

virtual int GetPiece ()
 If you want only a part of the data, specify by setting the piece. More...

virtual void SetNumberOfPieces (int)
 If you want only a part of the data, specify by setting the piece. More...

virtual int GetNumberOfPieces ()
 If you want only a part of the data, specify by setting the piece. More...

virtual void SetNumberOfSubPieces (int)
 If you want only a part of the data, specify by setting the piece. More...

virtual int GetNumberOfSubPieces ()
 If you want only a part of the data, specify by setting the piece. More...

virtual void SetGhostLevel (int)
 Set the number of ghost cells to return. More...

virtual int GetGhostLevel ()
 Set the number of ghost cells to return. More...

virtual void SetSeamlessU (bool)
 Accessors / Mutators for handling seams on wrapping surfaces. More...

virtual bool GetSeamlessU ()
 Accessors / Mutators for handling seams on wrapping surfaces. More...

virtual void SeamlessUOn ()
 Accessors / Mutators for handling seams on wrapping surfaces. More...

virtual void SeamlessUOff ()
 Accessors / Mutators for handling seams on wrapping surfaces. More...

virtual void SetSeamlessV (bool)
 Accessors / Mutators for handling seams on wrapping surfaces. More...

virtual bool GetSeamlessV ()
 Accessors / Mutators for handling seams on wrapping surfaces. More...

virtual void SeamlessVOn ()
 Accessors / Mutators for handling seams on wrapping surfaces. More...

virtual void SeamlessVOff ()
 Accessors / Mutators for handling seams on wrapping surfaces. More...

- Public Member Functions inherited from vtkMapper
vtkMapperNewInstance () const

vtkMTimeType GetMTime () override
 Overload standard modified time function. More...

void ReleaseGraphicsResources (vtkWindow *) override
 Release any graphics resources that are being consumed by this mapper. More...

virtual void CreateDefaultLookupTable ()
 Create default lookup table. More...

const char * GetColorModeAsString ()
 Return the method of coloring scalar data. More...

virtual void SetScalarMode (int)
 Control how the filter works with scalar point data and cell attribute data. More...

virtual int GetScalarMode ()

void SetScalarModeToDefault ()

void SetScalarModeToUsePointData ()

void SetScalarModeToUseCellData ()

void SetScalarModeToUsePointFieldData ()

void SetScalarModeToUseCellFieldData ()

void SetScalarModeToUseFieldData ()

virtual void SetFieldDataTupleId (vtkIdType)

virtual vtkIdType GetFieldDataTupleId ()

virtual char * GetArrayName ()
 Set/Get the array name or number and component to color by. More...

virtual void SetArrayName (const char *)

virtual int GetArrayId ()

virtual void SetArrayId (int)

virtual int GetArrayAccessMode ()

virtual void SetArrayAccessMode (int)

virtual int GetArrayComponent ()

virtual void SetArrayComponent (int)

const char * GetScalarModeAsString ()
 Return the method for obtaining scalar data. More...

void SetRenderTime (double time)
 This instance variable is used by vtkLODActor to determine which mapper to use. More...

virtual double GetRenderTime ()

vtkDataSetGetInput ()
 Get the input as a vtkDataSet. More...

vtkDataSetGetInputAsDataSet ()
 Get the input to this mapper as a vtkDataSet, instead of as a more specialized data type that the subclass may return from GetInput(). More...

virtual bool GetSupportsSelection ()
 WARNING: INTERNAL METHOD - NOT INTENDED FOR GENERAL USE DO NOT USE THIS METHOD OUTSIDE OF THE RENDERING PROCESS Used by vtkHardwareSelector to determine if the prop supports hardware selection. More...

virtual int CanUseTextureMapForColoring (vtkDataObject *input)
 Returns if we can use texture maps for scalar coloring. More...

void ClearColorArrays ()
 Call to force a rebuild of color result arrays on next MapScalars. More...

vtkUnsignedCharArrayGetColorMapColors ()
 Provide read access to the color array. More...

vtkFloatArrayGetColorCoordinates ()
 Provide read access to the color texture coordinate array. More...

vtkImageDataGetColorTextureMap ()
 Provide read access to the color texture array. More...

void SetLookupTable (vtkScalarsToColors *lut)
 Specify a lookup table for the mapper to use. More...

vtkScalarsToColorsGetLookupTable ()
 Specify a lookup table for the mapper to use. More...

virtual void SetScalarVisibility (vtkTypeBool)
 Turn on/off flag to control whether scalar data is used to color objects. More...

virtual vtkTypeBool GetScalarVisibility ()
 Turn on/off flag to control whether scalar data is used to color objects. More...

virtual void ScalarVisibilityOn ()
 Turn on/off flag to control whether scalar data is used to color objects. More...

virtual void ScalarVisibilityOff ()
 Turn on/off flag to control whether scalar data is used to color objects. More...

virtual void SetStatic (vtkTypeBool)
 Turn on/off flag to control whether the mapper's data is static. More...

virtual vtkTypeBool GetStatic ()
 Turn on/off flag to control whether the mapper's data is static. More...

virtual void StaticOn ()
 Turn on/off flag to control whether the mapper's data is static. More...

virtual void StaticOff ()
 Turn on/off flag to control whether the mapper's data is static. More...

virtual void SetColorMode (int)
 default (ColorModeToDefault), unsigned char scalars are treated as colors, and NOT mapped through the lookup table, while everything else is. More...

virtual int GetColorMode ()
 default (ColorModeToDefault), unsigned char scalars are treated as colors, and NOT mapped through the lookup table, while everything else is. More...

void SetColorModeToDefault ()
 default (ColorModeToDefault), unsigned char scalars are treated as colors, and NOT mapped through the lookup table, while everything else is. More...

void SetColorModeToMapScalars ()
 default (ColorModeToDefault), unsigned char scalars are treated as colors, and NOT mapped through the lookup table, while everything else is. More...

void SetColorModeToDirectScalars ()
 default (ColorModeToDefault), unsigned char scalars are treated as colors, and NOT mapped through the lookup table, while everything else is. More...

virtual void SetInterpolateScalarsBeforeMapping (vtkTypeBool)
 By default, vertex color is used to map colors to a surface. More...

virtual vtkTypeBool GetInterpolateScalarsBeforeMapping ()
 By default, vertex color is used to map colors to a surface. More...

virtual void InterpolateScalarsBeforeMappingOn ()
 By default, vertex color is used to map colors to a surface. More...

virtual void InterpolateScalarsBeforeMappingOff ()
 By default, vertex color is used to map colors to a surface. More...

virtual void SetUseLookupTableScalarRange (vtkTypeBool)
 Control whether the mapper sets the lookuptable range based on its own ScalarRange, or whether it will use the LookupTable ScalarRange regardless of it's own setting. More...

virtual vtkTypeBool GetUseLookupTableScalarRange ()
 Control whether the mapper sets the lookuptable range based on its own ScalarRange, or whether it will use the LookupTable ScalarRange regardless of it's own setting. More...

virtual void UseLookupTableScalarRangeOn ()
 Control whether the mapper sets the lookuptable range based on its own ScalarRange, or whether it will use the LookupTable ScalarRange regardless of it's own setting. More...

virtual void UseLookupTableScalarRangeOff ()
 Control whether the mapper sets the lookuptable range based on its own ScalarRange, or whether it will use the LookupTable ScalarRange regardless of it's own setting. More...

virtual void SetScalarRange (double, double)
 Specify range in terms of scalar minimum and maximum (smin,smax). More...

void SetScalarRange (double[2])
 Specify range in terms of scalar minimum and maximum (smin,smax). More...

virtual double * GetScalarRange ()
 Specify range in terms of scalar minimum and maximum (smin,smax). More...

virtual void GetScalarRange (double data[2])
 Specify range in terms of scalar minimum and maximum (smin,smax). More...

void SelectColorArray (int arrayNum)
 When ScalarMode is set to UsePointFieldData or UseCellFieldData, you can specify which array to use for coloring using these methods. More...

void SelectColorArray (const char *arrayName)
 When ScalarMode is set to UsePointFieldData or UseCellFieldData, you can specify which array to use for coloring using these methods. More...

void ColorByArrayComponent (int arrayNum, int component)
 Legacy: These methods used to be used to specify the array component. More...

void ColorByArrayComponent (const char *arrayName, int component)
 Legacy: These methods used to be used to specify the array component. More...

void SetRelativeCoincidentTopologyPolygonOffsetParameters (double factor, double units)
 Used to set the polygon offset values relative to the global Used when ResolveCoincidentTopology is set to PolygonOffset. More...

void GetRelativeCoincidentTopologyPolygonOffsetParameters (double &factor, double &units)
 Used to set the polygon offset values relative to the global Used when ResolveCoincidentTopology is set to PolygonOffset. More...

void SetRelativeCoincidentTopologyLineOffsetParameters (double factor, double units)
 Used to set the line offset values relative to the global Used when ResolveCoincidentTopology is set to PolygonOffset. More...

void GetRelativeCoincidentTopologyLineOffsetParameters (double &factor, double &units)
 Used to set the line offset values relative to the global Used when ResolveCoincidentTopology is set to PolygonOffset. More...

void SetRelativeCoincidentTopologyPointOffsetParameter (double units)
 Used to set the point offset value relative to the global Used when ResolveCoincidentTopology is set to PolygonOffset. More...

void GetRelativeCoincidentTopologyPointOffsetParameter (double &units)
 Used to set the point offset value relative to the global Used when ResolveCoincidentTopology is set to PolygonOffset. More...

void GetCoincidentTopologyPolygonOffsetParameters (double &factor, double &units)
 Get the net parameters for handling coincident topology obtained by summing the global values with the relative values. More...

void GetCoincidentTopologyLineOffsetParameters (double &factor, double &units)
 Get the net parameters for handling coincident topology obtained by summing the global values with the relative values. More...

void GetCoincidentTopologyPointOffsetParameter (double &units)
 Get the net parameters for handling coincident topology obtained by summing the global values with the relative values. More...

virtual vtkUnsignedCharArrayMapScalars (double alpha)
 Map the scalars (if there are any scalars and ScalarVisibility is on) through the lookup table, returning an unsigned char RGBA array. More...

virtual vtkUnsignedCharArrayMapScalars (double alpha, int &cellFlag)
 Map the scalars (if there are any scalars and ScalarVisibility is on) through the lookup table, returning an unsigned char RGBA array. More...

virtual vtkUnsignedCharArrayMapScalars (vtkDataSet *input, double alpha)
 Map the scalars (if there are any scalars and ScalarVisibility is on) through the lookup table, returning an unsigned char RGBA array. More...

virtual vtkUnsignedCharArrayMapScalars (vtkDataSet *input, double alpha, int &cellFlag)
 Map the scalars (if there are any scalars and ScalarVisibility is on) through the lookup table, returning an unsigned char RGBA array. More...

virtual vtkSelectionGetSelection ()
 Set/Get selection used to display particular points or cells in a second pass. More...

virtual void SetSelection (vtkSelection *)
 Set/Get selection used to display particular points or cells in a second pass. More...

- Public Member Functions inherited from vtkAbstractMapper3D
vtkAbstractMapper3DNewInstance () const

double GetLength ()
 Return the diagonal length of this mappers bounding box. More...

virtual vtkTypeBool IsARayCastMapper ()
 Is this a ray cast mapper? A subclass would return 1 if the ray caster is needed to generate an image from this mapper. More...

virtual vtkTypeBool IsARenderIntoImageMapper ()
 Is this a "render into image" mapper? A subclass would return 1 if the mapper produces an image by rendering into a software image buffer. More...

void GetClippingPlaneInDataCoords (vtkMatrix4x4 *propMatrix, int i, double planeEquation[4])
 Get the ith clipping plane as a homogeneous plane equation. More...

double * GetCenter ()
 Return the Center of this mapper's data. More...

void GetCenter (double center[3])
 Return the Center of this mapper's data. More...

- Public Member Functions inherited from vtkAbstractMapper
vtkAbstractMapperNewInstance () const

void SetClippingPlanes (vtkPlanes *planes)
 An alternative way to set clipping planes: use up to six planes found in the supplied instance of the implicit function vtkPlanes. More...

int GetNumberOfClippingPlanes ()
 Get the number of clipping planes. More...

virtual double GetTimeToDraw ()
 Get the time required to draw the geometry last time it was rendered. More...

void AddClippingPlane (vtkPlane *plane)
 Specify clipping planes to be applied when the data is mapped (at most 6 clipping planes can be specified). More...

void RemoveClippingPlane (vtkPlane *plane)
 Specify clipping planes to be applied when the data is mapped (at most 6 clipping planes can be specified). More...

void RemoveAllClippingPlanes ()
 Specify clipping planes to be applied when the data is mapped (at most 6 clipping planes can be specified). More...

virtual void SetClippingPlanes (vtkPlaneCollection *)
 Get/Set the vtkPlaneCollection which specifies the clipping planes. More...

virtual vtkPlaneCollectionGetClippingPlanes ()
 Get/Set the vtkPlaneCollection which specifies the clipping planes. More...

- Public Member Functions inherited from vtkAlgorithm
vtkAlgorithmNewInstance () const

vtkTypeBool HasExecutive ()
 Check whether this algorithm has an assigned executive. More...

vtkExecutiveGetExecutive ()
 Get this algorithm's executive. More...

virtual void SetExecutive (vtkExecutive *executive)
 Set this algorithm's executive. More...

vtkTypeBool ProcessRequest (vtkInformation *request, vtkCollection *inInfo, vtkInformationVector *outInfo)
 Version of ProcessRequest() that is wrapped. More...

virtual int ComputePipelineMTime (vtkInformation *request, vtkInformationVector **inInfoVec, vtkInformationVector *outInfoVec, int requestFromOutputPort, vtkMTimeType *mtime)
 A special version of ProcessRequest meant specifically for the pipeline modified time request. More...

virtual int ModifyRequest (vtkInformation *request, int when)
 This method gives the algorithm a chance to modify the contents of a request before or after (specified in the when argument) it is forwarded. More...

vtkInformationGetInputPortInformation (int port)
 Get the information object associated with an input port. More...

vtkInformationGetOutputPortInformation (int port)
 Get the information object associated with an output port. More...

int GetNumberOfInputPorts ()
 Get the number of input ports used by the algorithm. More...

int GetNumberOfOutputPorts ()
 Get the number of output ports provided by the algorithm. More...

void SetAbortExecuteAndUpdateTime ()
 Set AbortExecute Flag and update LastAbortTime. More...

void UpdateProgress (double amount)
 Update the progress of the process object. More...

bool CheckAbort ()
 Checks to see if this filter should abort. More...

virtual void SetInputArrayToProcess (int idx, int port, int connection, const char *fieldAssociation, const char *attributeTypeorName)
 String based versions of SetInputArrayToProcess(). More...

vtkInformationGetInputArrayInformation (int idx)
 Get the info object for the specified input array to this algorithm. More...

void RemoveAllInputs ()
 Remove all the input data. More...

vtkDataObjectGetOutputDataObject (int port)
 Get the data object that will contain the algorithm output for the given port. More...

vtkDataObjectGetInputDataObject (int port, int connection)
 Get the data object that will contain the algorithm input for the given port and given connection. More...

virtual void RemoveInputConnection (int port, vtkAlgorithmOutput *input)
 Remove a connection from the given input port index. More...

virtual void RemoveInputConnection (int port, int idx)
 Remove a connection given by index idx. More...

virtual void RemoveAllInputConnections (int port)
 Removes all input connections. More...

virtual void SetInputDataObject (int port, vtkDataObject *data)
 Sets the data-object as an input on the given port index. More...

virtual void SetInputDataObject (vtkDataObject *data)

virtual void AddInputDataObject (int port, vtkDataObject *data)
 Add the data-object as an input to this given port. More...

virtual void AddInputDataObject (vtkDataObject *data)

vtkAlgorithmOutputGetOutputPort (int index)
 Get a proxy object corresponding to the given output port of this algorithm. More...

vtkAlgorithmOutputGetOutputPort ()

int GetNumberOfInputConnections (int port)
 Get the number of inputs currently connected to a port. More...

int GetTotalNumberOfInputConnections ()
 Get the total number of inputs for this algorithm. More...

vtkAlgorithmOutputGetInputConnection (int port, int index)
 Get the algorithm output port connected to an input port. More...

vtkAlgorithmGetInputAlgorithm (int port, int index, int &algPort)
 Returns the algorithm and the output port index of that algorithm connected to a port-index pair. More...

vtkAlgorithmGetInputAlgorithm (int port, int index)
 Returns the algorithm connected to a port-index pair. More...

vtkAlgorithmGetInputAlgorithm ()
 Equivalent to GetInputAlgorithm(0, 0). More...

vtkExecutiveGetInputExecutive (int port, int index)
 Returns the executive associated with a particular input connection. More...

vtkExecutiveGetInputExecutive ()
 Equivalent to GetInputExecutive(0, 0) More...

vtkInformationGetInputInformation (int port, int index)
 Return the information object that is associated with a particular input connection. More...

vtkInformationGetInputInformation ()
 Equivalent to GetInputInformation(0, 0) More...

vtkInformationGetOutputInformation (int port)
 Return the information object that is associated with a particular output port. More...

virtual int UpdatePiece (int piece, int numPieces, int ghostLevels, const int extents[6]=nullptr)
 Convenience method to update an algorithm after passing requests to its first output port. More...

virtual int UpdateExtent (const int extents[6])
 Convenience method to update an algorithm after passing requests to its first output port. More...

virtual int UpdateTimeStep (double time, int piece=-1, int numPieces=1, int ghostLevels=0, const int extents[6]=nullptr)
 Convenience method to update an algorithm after passing requests to its first output port. More...

virtual void UpdateInformation ()
 Bring the algorithm's information up-to-date. More...

virtual void UpdateDataObject ()
 Create output object(s). More...

virtual void PropagateUpdateExtent ()
 Propagate meta-data upstream. More...

virtual void UpdateWholeExtent ()
 Bring this algorithm's outputs up-to-date. More...

void ConvertTotalInputToPortConnection (int ind, int &port, int &conn)
 Convenience routine to convert from a linear ordering of input connections to a port/connection pair. More...

void RemoveNoPriorTemporalAccessInformationKey ()
 Removes any information key vtkStreamingDemandDrivenPipeline::NO_PRIOR_TEMPORAL_ACCESS() to all output ports of this vtkAlgorithm. More...

virtual vtkInformationGetInformation ()
 Set/Get the information object associated with this algorithm. More...

virtual void SetInformation (vtkInformation *)
 Set/Get the information object associated with this algorithm. More...

bool UsesGarbageCollector () const override
 Participate in garbage collection. More...

virtual void SetAbortExecute (vtkTypeBool)
 Set/Get the AbortExecute flag for the process object. More...

virtual vtkTypeBool GetAbortExecute ()
 Set/Get the AbortExecute flag for the process object. More...

virtual void AbortExecuteOn ()
 Set/Get the AbortExecute flag for the process object. More...

virtual void AbortExecuteOff ()
 Set/Get the AbortExecute flag for the process object. More...

virtual double GetProgress ()
 Get the execution progress of a process object. More...

void SetContainerAlgorithm (vtkAlgorithm *containerAlg)
 Set/get a Container algorithm for this algorithm. More...

vtkAlgorithmGetContainerAlgorithm ()
 Set/get a Container algorithm for this algorithm. More...

virtual void SetAbortOutput (bool)
 Set/Get an internal variable used to communicate between the algorithm and executive. More...

virtual bool GetAbortOutput ()
 Set/Get an internal variable used to communicate between the algorithm and executive. More...

void SetProgressShiftScale (double shift, double scale)
 Specify the shift and scale values to use to apply to the progress amount when UpdateProgress is called. More...

virtual double GetProgressShift ()
 Specify the shift and scale values to use to apply to the progress amount when UpdateProgress is called. More...

virtual double GetProgressScale ()
 Specify the shift and scale values to use to apply to the progress amount when UpdateProgress is called. More...

void SetProgressText (const char *ptext)
 Set the current text message associated with the progress state. More...

virtual char * GetProgressText ()
 Set the current text message associated with the progress state. More...

virtual unsigned long GetErrorCode ()
 The error code contains a possible error that occurred while reading or writing the file. More...

virtual void SetInputConnection (int port, vtkAlgorithmOutput *input)
 Set the connection for the given input port index. More...

virtual void SetInputConnection (vtkAlgorithmOutput *input)
 Set the connection for the given input port index. More...

virtual void AddInputConnection (int port, vtkAlgorithmOutput *input)
 Add a connection to the given input port index. More...

virtual void AddInputConnection (vtkAlgorithmOutput *input)
 Add a connection to the given input port index. More...

virtual void SetReleaseDataFlag (vtkTypeBool)
 Turn release data flag on or off for all output ports. More...

virtual vtkTypeBool GetReleaseDataFlag ()
 Turn release data flag on or off for all output ports. More...

void ReleaseDataFlagOn ()
 Turn release data flag on or off for all output ports. More...

void ReleaseDataFlagOff ()
 Turn release data flag on or off for all output ports. More...

int UpdateExtentIsEmpty (vtkInformation *pinfo, vtkDataObject *output)
 This detects when the UpdateExtent will generate no data This condition is satisfied when the UpdateExtent has zero volume (0,-1,...) or the UpdateNumberOfPieces is 0. More...

int UpdateExtentIsEmpty (vtkInformation *pinfo, int extentType)
 This detects when the UpdateExtent will generate no data This condition is satisfied when the UpdateExtent has zero volume (0,-1,...) or the UpdateNumberOfPieces is 0. More...

int * GetUpdateExtent ()
 These functions return the update extent for output ports that use 3D extents. More...

int * GetUpdateExtent (int port)
 These functions return the update extent for output ports that use 3D extents. More...

void GetUpdateExtent (int &x0, int &x1, int &y0, int &y1, int &z0, int &z1)
 These functions return the update extent for output ports that use 3D extents. More...

void GetUpdateExtent (int port, int &x0, int &x1, int &y0, int &y1, int &z0, int &z1)
 These functions return the update extent for output ports that use 3D extents. More...

void GetUpdateExtent (int extent[6])
 These functions return the update extent for output ports that use 3D extents. More...

void GetUpdateExtent (int port, int extent[6])
 These functions return the update extent for output ports that use 3D extents. More...

int GetUpdatePiece ()
 These functions return the update extent for output ports that use piece extents. More...

int GetUpdatePiece (int port)
 These functions return the update extent for output ports that use piece extents. More...

int GetUpdateNumberOfPieces ()
 These functions return the update extent for output ports that use piece extents. More...

int GetUpdateNumberOfPieces (int port)
 These functions return the update extent for output ports that use piece extents. More...

int GetUpdateGhostLevel ()
 These functions return the update extent for output ports that use piece extents. More...

int GetUpdateGhostLevel (int port)
 These functions return the update extent for output ports that use piece extents. More...

void SetProgressObserver (vtkProgressObserver *)
 If an ProgressObserver is set, the algorithm will report progress through it rather than directly. More...

virtual vtkProgressObserverGetProgressObserver ()
 If an ProgressObserver is set, the algorithm will report progress through it rather than directly. More...

void SetNoPriorTemporalAccessInformationKey (int key)
 Set to all output ports of this algorithm the information key vtkStreamingDemandDrivenPipeline::NO_PRIOR_TEMPORAL_ACCESS(). More...

void SetNoPriorTemporalAccessInformationKey ()
 Set to all output ports of this algorithm the information key vtkStreamingDemandDrivenPipeline::NO_PRIOR_TEMPORAL_ACCESS(). More...

- Public Member Functions inherited from vtkObject
 vtkBaseTypeMacro (vtkObject, vtkObjectBase)

virtual void DebugOn ()
 Turn debugging output on. More...

virtual void DebugOff ()
 Turn debugging output off. More...

bool GetDebug ()
 Get the value of the debug flag. More...

void SetDebug (bool debugFlag)
 Set the value of the debug flag. More...

virtual void Modified ()
 Update the modification time for this object. More...

void RemoveObserver (unsigned long tag)

void RemoveObservers (unsigned long event)

void RemoveObservers (const char *event)

void RemoveAllObservers ()

vtkTypeBool HasObserver (unsigned long event)

vtkTypeBool HasObserver (const char *event)

vtkTypeBool InvokeEvent (unsigned long event)

vtkTypeBool InvokeEvent (const char *event)

std::string GetObjectDescription () const override
 The object description printed in messages and PrintSelf output. More...

unsigned long AddObserver (unsigned long event, vtkCommand *, float priority=0.0f)
 Allow people to add/remove/invoke observers (callbacks) to any VTK object. More...

unsigned long AddObserver (const char *event, vtkCommand *, float priority=0.0f)
 Allow people to add/remove/invoke observers (callbacks) to any VTK object. More...

vtkCommandGetCommand (unsigned long tag)
 Allow people to add/remove/invoke observers (callbacks) to any VTK object. More...

void RemoveObserver (vtkCommand *)
 Allow people to add/remove/invoke observers (callbacks) to any VTK object. More...

void RemoveObservers (unsigned long event, vtkCommand *)
 Allow people to add/remove/invoke observers (callbacks) to any VTK object. More...

void RemoveObservers (const char *event, vtkCommand *)
 Allow people to add/remove/invoke observers (callbacks) to any VTK object. More...

vtkTypeBool HasObserver (unsigned long event, vtkCommand *)
 Allow people to add/remove/invoke observers (callbacks) to any VTK object. More...

vtkTypeBool HasObserver (const char *event, vtkCommand *)
 Allow people to add/remove/invoke observers (callbacks) to any VTK object. More...

template<class U , class T >
unsigned long AddObserver (unsigned long event, U observer, void(T::*callback)(), float priority=0.0f)
 Overloads to AddObserver that allow developers to add class member functions as callbacks for events. More...

template<class U , class T >
unsigned long AddObserver (unsigned long event, U observer, void(T::*callback)(vtkObject *, unsigned long, void *), float priority=0.0f)
 Overloads to AddObserver that allow developers to add class member functions as callbacks for events. More...

template<class U , class T >
unsigned long AddObserver (unsigned long event, U observer, bool(T::*callback)(vtkObject *, unsigned long, void *), float priority=0.0f)
 Allow user to set the AbortFlagOn() with the return value of the callback method. More...

vtkTypeBool InvokeEvent (unsigned long event, void *callData)
 This method invokes an event and return whether the event was aborted or not. More...

vtkTypeBool InvokeEvent (const char *event, void *callData)
 This method invokes an event and return whether the event was aborted or not. More...

virtual void SetObjectName (const std::string &objectName)
 Set/get the name of this object for reporting purposes. More...

virtual std::string GetObjectName () const
 Set/get the name of this object for reporting purposes. More...

- Public Member Functions inherited from vtkObjectBase
const char * GetClassName () const
 Return the class name as a string. More...

virtual vtkIdType GetNumberOfGenerationsFromBase (const char *name)
 Given the name of a base class of this class type, return the distance of inheritance between this class type and the named class (how many generations of inheritance are there between this class and the named class). More...

virtual void Delete ()
 Delete a VTK object. More...

virtual void FastDelete ()
 Delete a reference to this object. More...

void InitializeObjectBase ()

void Print (ostream &os)
 Print an object to an ostream. More...

void Register (vtkObjectBase *o)
 Increase the reference count (mark as used by another object). More...

virtual void UnRegister (vtkObjectBase *o)
 Decrease the reference count (release by another object). More...

int GetReferenceCount ()
 Return the current reference count of this object. More...

void SetReferenceCount (int)
 Sets the reference count. More...

bool GetIsInMemkind () const
 A local state flag that remembers whether this object lives in the normal or extended memory space. More...

virtual void PrintHeader (ostream &os, vtkIndent indent)
 Methods invoked by print to print information about the object including superclasses. More...

virtual void PrintTrailer (ostream &os, vtkIndent indent)
 Methods invoked by print to print information about the object including superclasses. More...


Static Public Member Functions

static vtkCompositePolyDataMapperNew ()

static vtkTypeBool IsTypeOf (const char *type)

static vtkCompositePolyDataMapperSafeDownCast (vtkObjectBase *o)

- Static Public Member Functions inherited from vtkPolyDataMapper
static vtkPolyDataMapperNew ()

static vtkTypeBool IsTypeOf (const char *type)

static vtkPolyDataMapperSafeDownCast (vtkObjectBase *o)

- Static Public Member Functions inherited from vtkMapper
static vtkTypeBool IsTypeOf (const char *type)

static vtkMapperSafeDownCast (vtkObjectBase *o)

static vtkSmartPointer< vtkImageDataBuildColorTextureImage (vtkScalarsToColors *lkup, int colorMode)
 Create an image of the lookup table lkup. More...

static void SetResolveCoincidentTopology (int val)
 Set/Get a global flag that controls whether coincident topology (e.g., a line on top of a polygon) is shifted to avoid z-buffer resolution (and hence rendering problems). More...

static int GetResolveCoincidentTopology ()
 Set/Get a global flag that controls whether coincident topology (e.g., a line on top of a polygon) is shifted to avoid z-buffer resolution (and hence rendering problems). More...

static void SetResolveCoincidentTopologyToDefault ()
 Set/Get a global flag that controls whether coincident topology (e.g., a line on top of a polygon) is shifted to avoid z-buffer resolution (and hence rendering problems). More...

static void SetResolveCoincidentTopologyToOff ()
 Set/Get a global flag that controls whether coincident topology (e.g., a line on top of a polygon) is shifted to avoid z-buffer resolution (and hence rendering problems). More...

static void SetResolveCoincidentTopologyToPolygonOffset ()
 Set/Get a global flag that controls whether coincident topology (e.g., a line on top of a polygon) is shifted to avoid z-buffer resolution (and hence rendering problems). More...

static void SetResolveCoincidentTopologyToShiftZBuffer ()
 Set/Get a global flag that controls whether coincident topology (e.g., a line on top of a polygon) is shifted to avoid z-buffer resolution (and hence rendering problems). More...

static void SetResolveCoincidentTopologyPolygonOffsetParameters (double factor, double units)
 Used to set the polygon offset scale factor and units. More...

static void GetResolveCoincidentTopologyPolygonOffsetParameters (double &factor, double &units)
 Used to set the polygon offset scale factor and units. More...

static void SetResolveCoincidentTopologyLineOffsetParameters (double factor, double units)
 Used to set the line offset scale factor and units. More...

static void GetResolveCoincidentTopologyLineOffsetParameters (double &factor, double &units)
 Used to set the line offset scale factor and units. More...

static void SetResolveCoincidentTopologyPointOffsetParameter (double units)
 Used to set the point offset value Used when ResolveCoincidentTopology is set to PolygonOffset. More...

static void GetResolveCoincidentTopologyPointOffsetParameter (double &units)
 Used to set the point offset value Used when ResolveCoincidentTopology is set to PolygonOffset. More...

static void SetResolveCoincidentTopologyPolygonOffsetFaces (int faces)
 Used when ResolveCoincidentTopology is set to PolygonOffset. More...

static int GetResolveCoincidentTopologyPolygonOffsetFaces ()
 Used when ResolveCoincidentTopology is set to PolygonOffset. More...

static void SetResolveCoincidentTopologyZShift (double val)
 Used to set the z-shift if ResolveCoincidentTopology is set to ShiftZBuffer. More...

static double GetResolveCoincidentTopologyZShift ()
 Used to set the z-shift if ResolveCoincidentTopology is set to ShiftZBuffer. More...

- Static Public Member Functions inherited from vtkAbstractMapper3D
static vtkTypeBool IsTypeOf (const char *type)

static vtkAbstractMapper3DSafeDownCast (vtkObjectBase *o)

- Static Public Member Functions inherited from vtkAbstractMapper
static vtkTypeBool IsTypeOf (const char *type)

static vtkAbstractMapperSafeDownCast (vtkObjectBase *o)

static vtkDataArrayGetScalars (vtkDataSet *input, int scalarMode, int arrayAccessMode, int arrayId, const char *arrayName, int &cellFlag)
 Internal helper function for getting the active scalars. More...

static vtkAbstractArrayGetAbstractScalars (vtkDataSet *input, int scalarMode, int arrayAccessMode, int arrayId, const char *arrayName, int &cellFlag)
 Internal helper function for getting the active scalars as an abstract array. More...

static vtkUnsignedCharArrayGetGhostArray (vtkDataSet *input, int scalarMode, unsigned char &ghostsToSkip)
 Returns the ghost array associated with the corresponding scalar mode, if present. More...

- Static Public Member Functions inherited from vtkAlgorithm
static vtkAlgorithmNew ()

static vtkTypeBool IsTypeOf (const char *type)

static vtkAlgorithmSafeDownCast (vtkObjectBase *o)

static vtkInformationIntegerKeyINPUT_IS_OPTIONAL ()
 Keys used to specify input port requirements. More...

static vtkInformationIntegerKeyINPUT_IS_REPEATABLE ()

static vtkInformationInformationVectorKeyINPUT_REQUIRED_FIELDS ()

static vtkInformationStringVectorKeyINPUT_REQUIRED_DATA_TYPE ()

static vtkInformationInformationVectorKeyINPUT_ARRAYS_TO_PROCESS ()

static vtkInformationIntegerKeyINPUT_PORT ()

static vtkInformationIntegerKeyINPUT_CONNECTION ()

static vtkInformationIntegerKeyCAN_PRODUCE_SUB_EXTENT ()
 This key tells the executive that a particular output port is capable of producing an arbitrary subextent of the whole extent. More...

static vtkInformationIntegerKeyCAN_HANDLE_PIECE_REQUEST ()
 Key that tells the pipeline that a particular algorithm can or cannot handle piece request. More...

static vtkInformationIntegerKeyABORTED ()

static void SetDefaultExecutivePrototype (vtkExecutive *proto)
 If the DefaultExecutivePrototype is set, a copy of it is created in CreateDefaultExecutive() using NewInstance(). More...

- Static Public Member Functions inherited from vtkObject
static vtkObjectNew ()
 Create an object with Debug turned off, modified time initialized to zero, and reference counting on. More...

static void BreakOnError ()
 This method is called when vtkErrorMacro executes. More...

static void SetGlobalWarningDisplay (vtkTypeBool val)
 This is a global flag that controls whether any debug, warning or error messages are displayed. More...

static void GlobalWarningDisplayOn ()
 This is a global flag that controls whether any debug, warning or error messages are displayed. More...

static void GlobalWarningDisplayOff ()
 This is a global flag that controls whether any debug, warning or error messages are displayed. More...

static vtkTypeBool GetGlobalWarningDisplay ()
 This is a global flag that controls whether any debug, warning or error messages are displayed. More...

- Static Public Member Functions inherited from vtkObjectBase
static vtkTypeBool IsTypeOf (const char *name)
 Return 1 if this class type is the same type of (or a subclass of) the named class. More...

static vtkIdType GetNumberOfGenerationsFromBaseType (const char *name)
 Given a the name of a base class of this class type, return the distance of inheritance between this class type and the named class (how many generations of inheritance are there between this class and the named class). More...

static vtkObjectBaseNew ()
 Create an object with Debug turned off, modified time initialized to zero, and reference counting on. More...

static void SetMemkindDirectory (const char *directoryname)
 The name of a directory, ideally mounted -o dax, to memory map an extended memory space within. More...

static bool GetUsingMemkind ()
 A global state flag that controls whether vtkObjects are constructed in the usual way (the default) or within the extended memory space. More...


Protected Member Functions

virtual vtkObjectBaseNewInstanceInternal () const

 vtkCompositePolyDataMapper ()

 ~vtkCompositePolyDataMapper () override

MapperHashType InsertPolyData (vtkPolyData *polydata, const unsigned int &flatIndex)

vtkExecutiveCreateDefaultExecutive () override
 We need to override this method because the standard streaming demand driven pipeline is not what we want - we are expecting hierarchical data as input. More...

int FillInputPortInformation (int port, vtkInformation *info) override
 Need to define the type of data handled by this mapper. More...

virtual vtkCompositePolyDataMapperDelegatorCreateADelegator ()
 This is the build method for creating the delegator. More...

virtual void PreRender (const std::vector< vtkSmartPointer< vtkCompositePolyDataMapperDelegator >> &, vtkRenderer *, vtkActor *)
 Invoked just before all delegators render their datasets. More...

virtual void PostRender (const std::vector< vtkSmartPointer< vtkCompositePolyDataMapperDelegator >> &, vtkRenderer *, vtkActor *)
 Invoked just after all delegators render their datasets. More...

vtkPolyDataMapper::MapperHashType GenerateHash (vtkPolyData *polydata) override
 Creates an empty polydata mapper and asks the mapper to hash the polydata. More...

virtual vtkDataObjectTreeIteratorMakeAnIterator (vtkCompositeDataSet *dataset)
 Initialize an iterator for the composite dataset. More...

void ComputeBounds () override
 Need to loop over the hierarchy to compute bounds. More...

bool RecursiveHasTranslucentGeometry (vtkDataObject *dobj, unsigned int &flat_index)

void BuildRenderValues (vtkRenderer *renderer, vtkActor *actor, vtkDataObject *dobj, unsigned int &flat_index)

- Protected Member Functions inherited from vtkPolyDataMapper
 vtkPolyDataMapper ()

 ~vtkPolyDataMapper () override=default

int FillInputPortInformation (int, vtkInformation *) override
 Fill the input port information objects for this algorithm. More...

- Protected Member Functions inherited from vtkMapper
 vtkMapper ()

 ~vtkMapper () override

void MapScalarsToTexture (vtkAbstractArray *scalars, double alpha)

- Protected Member Functions inherited from vtkAbstractMapper3D
 vtkAbstractMapper3D ()

 ~vtkAbstractMapper3D () override=default

- Protected Member Functions inherited from vtkAbstractMapper
 vtkAbstractMapper ()

 ~vtkAbstractMapper () override

- Protected Member Functions inherited from vtkAlgorithm
 vtkAlgorithm ()

 ~vtkAlgorithm () override

bool CheckUpstreamAbort ()
 Checks to see if an upstream filter has been aborted. More...

virtual int FillOutputPortInformation (int port, vtkInformation *info)
 Fill the output port information objects for this algorithm. More...

virtual void SetNumberOfInputPorts (int n)
 Set the number of input ports used by the algorithm. More...

virtual void SetNumberOfOutputPorts (int n)
 Set the number of output ports provided by the algorithm. More...

int InputPortIndexInRange (int index, const char *action)

int OutputPortIndexInRange (int index, const char *action)

int GetInputArrayAssociation (int idx, vtkInformationVector **inputVector)
 Get the association of the actual data array for the input array specified by idx, this is only reasonable during the REQUEST_DATA pass. More...

vtkInformationGetInputArrayFieldInformation (int idx, vtkInformationVector **inputVector)
 This method takes in an index (as specified in SetInputArrayToProcess) and a pipeline information vector. More...

void ReportReferences (vtkGarbageCollector *) override

virtual void SetNthInputConnection (int port, int index, vtkAlgorithmOutput *input)
 Replace the Nth connection on the given input port. More...

virtual void SetNumberOfInputConnections (int port, int n)
 Set the number of input connections on the given input port. More...

void SetInputDataInternal (int port, vtkDataObject *input)
 These methods are used by subclasses to implement methods to set data objects directly as input. More...

void AddInputDataInternal (int port, vtkDataObject *input)

int GetInputArrayAssociation (int idx, int connection, vtkInformationVector **inputVector)
 Filters that have multiple connections on one port can use this signature. More...

int GetInputArrayAssociation (int idx, vtkDataObject *input)
 Filters that have multiple connections on one port can use this signature. More...

vtkDataArrayGetInputArrayToProcess (int idx, vtkInformationVector **inputVector)
 Get the actual data array for the input array specified by idx, this is only reasonable during the REQUEST_DATA pass. More...

vtkDataArrayGetInputArrayToProcess (int idx, vtkInformationVector **inputVector, int &association)
 Get the actual data array for the input array specified by idx, this is only reasonable during the REQUEST_DATA pass. More...

vtkDataArrayGetInputArrayToProcess (int idx, int connection, vtkInformationVector **inputVector)
 Filters that have multiple connections on one port can use this signature. More...

vtkDataArrayGetInputArrayToProcess (int idx, int connection, vtkInformationVector **inputVector, int &association)
 Filters that have multiple connections on one port can use this signature. More...

vtkDataArrayGetInputArrayToProcess (int idx, vtkDataObject *input)
 Filters that have multiple connections on one port can use this signature. More...

vtkDataArrayGetInputArrayToProcess (int idx, vtkDataObject *input, int &association)
 Filters that have multiple connections on one port can use this signature. More...

vtkAbstractArrayGetInputAbstractArrayToProcess (int idx, vtkInformationVector **inputVector)
 Get the actual data array for the input array specified by idx, this is only reasonable during the REQUEST_DATA pass. More...

vtkAbstractArrayGetInputAbstractArrayToProcess (int idx, vtkInformationVector **inputVector, int &association)
 Get the actual data array for the input array specified by idx, this is only reasonable during the REQUEST_DATA pass. More...

vtkAbstractArrayGetInputAbstractArrayToProcess (int idx, int connection, vtkInformationVector **inputVector)
 Filters that have multiple connections on one port can use this signature. More...

vtkAbstractArrayGetInputAbstractArrayToProcess (int idx, int connection, vtkInformationVector **inputVector, int &association)
 Filters that have multiple connections on one port can use this signature. More...

vtkAbstractArrayGetInputAbstractArrayToProcess (int idx, vtkDataObject *input)
 Filters that have multiple connections on one port can use this signature. More...

vtkAbstractArrayGetInputAbstractArrayToProcess (int idx, vtkDataObject *input, int &association)
 Filters that have multiple connections on one port can use this signature. More...

virtual void SetErrorCode (unsigned long)
 The error code contains a possible error that occurred while reading or writing the file. More...

- Protected Member Functions inherited from vtkObject
 vtkObject ()

 ~vtkObject () override

void RegisterInternal (vtkObjectBase *, vtkTypeBool check) override

void UnRegisterInternal (vtkObjectBase *, vtkTypeBool check) override

void InternalGrabFocus (vtkCommand *mouseEvents, vtkCommand *keypressEvents=nullptr)
 These methods allow a command to exclusively grab all events. More...

void InternalReleaseFocus ()
 These methods allow a command to exclusively grab all events. More...

- Protected Member Functions inherited from vtkObjectBase
 vtkObjectBase ()

virtual ~vtkObjectBase ()

 vtkObjectBase (const vtkObjectBase &)

void operator= (const vtkObjectBase &)


Protected Attributes

vtkNew< vtkPolyDataMapperPrototypeMapper
 A prototype of the object factory override mapper. More...

vtkSmartPointer< vtkCompositeDataDisplayAttributesCompositeAttributes
 Composite data set attributes. More...

bool ColorMissingArraysWithNanColor = false
 If the current 'color by' array is missing on some datasets, color these dataset by the LookupTable's NaN color, if the lookup table supports it. More...

vtkTimeStamp BoundsMTime
 Time stamp for computation of bounds. More...

char * PointIdArrayName = nullptr

char * CellIdArrayName = nullptr

char * ProcessIdArrayName = nullptr

char * CompositeIdArrayName = nullptr

vtkStateStorage TranslucentState

bool HasTranslucentGeometry = false

vtkStateStorage RenderValuesState

vtkStateStorage TempState

vtkTimeStamp DelegatorMTime

- Protected Attributes inherited from vtkPolyDataMapper
int Piece

int NumberOfPieces

int NumberOfSubPieces

int GhostLevel

bool SeamlessU

bool SeamlessV

int ShiftScaleMethod

bool PauseShiftScale

- Protected Attributes inherited from vtkMapper
vtkUnsignedCharArrayColors

vtkTypeBool InterpolateScalarsBeforeMapping

vtkFloatArrayColorCoordinates

vtkImageDataColorTextureMap

vtkScalarsToColorsLookupTable

vtkTypeBool ScalarVisibility

vtkTimeStamp BuildTime

double ScalarRange [2]

vtkTypeBool UseLookupTableScalarRange

int ColorMode

int ScalarMode

double RenderTime

int ArrayId

char * ArrayName

int ArrayComponent

int ArrayAccessMode

vtkIdType FieldDataTupleId

vtkTypeBool Static

double CoincidentPolygonFactor

double CoincidentPolygonOffset

double CoincidentLineFactor

double CoincidentLineOffset

double CoincidentPointOffset

vtkSelectionSelection = nullptr

- Protected Attributes inherited from vtkAbstractMapper3D
double Bounds [6]

double Center [3]

- Protected Attributes inherited from vtkAbstractMapper
vtkTimerLogTimer

double TimeToDraw

vtkWindowLastWindow

vtkPlaneCollectionClippingPlanes

- Protected Attributes inherited from vtkAlgorithm
vtkTimeStamp LastAbortCheckTime

vtkInformationInformation

double Progress

char * ProgressText

vtkProgressObserverProgressObserver

unsigned long ErrorCode
 The error code contains a possible error that occurred while reading or writing the file. More...

- Protected Attributes inherited from vtkObject
bool Debug

vtkTimeStamp MTime

vtkSubjectHelper * SubjectHelper

std::string ObjectName

- Protected Attributes inherited from vtkObjectBase
std::atomic< int32_t > ReferenceCount

vtkWeakPointerBase ** WeakPointers


Additional Inherited Members

- Public Attributes inherited from vtkAlgorithm
std::atomic< vtkTypeBoolAbortExecute

- Static Protected Member Functions inherited from vtkAlgorithm
static vtkInformationIntegerKeyPORT_REQUIREMENTS_FILLED ()

- Static Protected Member Functions inherited from vtkObjectBase
static vtkMallocingFunction GetCurrentMallocFunction ()

static vtkReallocingFunction GetCurrentReallocFunction ()

static vtkFreeingFunction GetCurrentFreeFunction ()

static vtkFreeingFunction GetAlternateFreeFunction ()

- Static Protected Attributes inherited from vtkAlgorithm
static vtkTimeStamp LastAbortTime

static vtkExecutiveDefaultExecutivePrototype


Detailed Description

a class that renders hierarchical polygonal data

This class uses a set of vtkPolyDataMappers to render input data which may be hierarchical. The input to this mapper may be either vtkPolyData or a vtkCompositeDataSet built from polydata. If something other than vtkPolyData is encountered, an error message will be produced.

See also
vtkPolyDataMapper
Events:
vtkCommand::EndEvent vtkCommand::StartEvent
Online Examples:

Tests:
vtkCompositePolyDataMapper (Tests)

Definition at line 64 of file vtkCompositePolyDataMapper.h.

Member Typedef Documentation

◆ Superclass

Definition at line 68 of file vtkCompositePolyDataMapper.h.

Constructor & Destructor Documentation

◆ vtkCompositePolyDataMapper()

vtkCompositePolyDataMapper::vtkCompositePolyDataMapper ( )
protected

◆ ~vtkCompositePolyDataMapper()

vtkCompositePolyDataMapper::~vtkCompositePolyDataMapper ( )
overrideprotected

Member Function Documentation

◆ New()

static vtkCompositePolyDataMapper* vtkCompositePolyDataMapper::New ( )
static

◆ IsTypeOf()

static vtkTypeBool vtkCompositePolyDataMapper::IsTypeOf ( const char *  type)
static

◆ IsA()

virtual vtkTypeBool vtkCompositePolyDataMapper::IsA ( const char *  name)
virtual

Return 1 if this class is the same type of (or a subclass of) the named class.

Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.

Reimplemented from vtkPolyDataMapper.

Reimplemented in vtkCompositeSurfaceLICMapper, and vtkHierarchicalPolyDataMapper.

◆ SafeDownCast()

static vtkCompositePolyDataMapper* vtkCompositePolyDataMapper::SafeDownCast ( vtkObjectBase o)
static

◆ NewInstanceInternal()

virtual vtkObjectBase* vtkCompositePolyDataMapper::NewInstanceInternal ( ) const
protectedvirtual

◆ NewInstance()

vtkCompositePolyDataMapper* vtkCompositePolyDataMapper::NewInstance ( ) const

◆ PrintSelf()

void vtkCompositePolyDataMapper::PrintSelf ( ostream &  os,
vtkIndent  indent
)
overridevirtual

Methods invoked by print to print information about the object including superclasses.

Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.

Reimplemented from vtkAbstractMapper3D.

Reimplemented in vtkCompositeSurfaceLICMapper, and vtkHierarchicalPolyDataMapper.

◆ Render()

void vtkCompositePolyDataMapper::Render ( vtkRenderer renderer,
vtkActor actor
)
overridevirtual

Standard method for rendering a mapper.

This method will be called by the actor.

Implements vtkMapper.

Reimplemented in vtkCompositeSurfaceLICMapper.

◆ GetBounds() [1/2]

double* vtkCompositePolyDataMapper::GetBounds ( )
overridevirtual

Standard vtkProp method to get 3D bounds of a 3D prop.

Implements vtkAbstractMapper3D.

◆ GetBounds() [2/2]

void vtkCompositePolyDataMapper::GetBounds ( double  bounds[6])
inlineoverridevirtual

Standard vtkProp method to get 3D bounds of a 3D prop.

Reimplemented from vtkAbstractMapper3D.

Definition at line 82 of file vtkCompositePolyDataMapper.h.

◆ ShallowCopy()

void vtkCompositePolyDataMapper::ShallowCopy ( vtkAbstractMapper mapper)
overridevirtual

Make a shallow copy of this mapper.

Reimplemented from vtkAbstractMapper.

◆ ReleaseGraphicsResources()

void vtkCompositePolyDataMapper::ReleaseGraphicsResources ( vtkWindow )
overridevirtual

Release the underlying resources associated with this mapper.

Reimplemented from vtkAbstractMapper.

◆ HasOpaqueGeometry()

bool vtkCompositePolyDataMapper::HasOpaqueGeometry ( )
overridevirtual

Some introspection on the type of data the mapper will render used by props to determine if they should invoke the mapper on a specific rendering pass.

Reimplemented from vtkMapper.

◆ HasTranslucentPolygonalGeometry()

bool vtkCompositePolyDataMapper::HasTranslucentPolygonalGeometry ( )
overridevirtual

Some introspection on the type of data the mapper will render used by props to determine if they should invoke the mapper on a specific rendering pass.

Reimplemented from vtkMapper.

◆ SetCompositeDataDisplayAttributes()

void vtkCompositePolyDataMapper::SetCompositeDataDisplayAttributes ( vtkCompositeDataDisplayAttributes attributes)

Set/get the composite data set attributes.

◆ GetCompositeDataDisplayAttributes()

vtkCompositeDataDisplayAttributes* vtkCompositePolyDataMapper::GetCompositeDataDisplayAttributes ( )

Set/get the composite data set attributes.

◆ SetBlockVisibility()

void vtkCompositePolyDataMapper::SetBlockVisibility ( unsigned int  index,
bool  visible
)

Set/get the visibility for a block given its flat index.

◆ GetBlockVisibility()

bool vtkCompositePolyDataMapper::GetBlockVisibility ( unsigned int  index)

Set/get the visibility for a block given its flat index.

◆ RemoveBlockVisibility()

void vtkCompositePolyDataMapper::RemoveBlockVisibility ( unsigned int  index)

Set/get the visibility for a block given its flat index.

◆ RemoveBlockVisibilities()

void vtkCompositePolyDataMapper::RemoveBlockVisibilities ( )

Set/get the visibility for a block given its flat index.

◆ SetBlockColor() [1/2]

void vtkCompositePolyDataMapper::SetBlockColor ( unsigned int  index,
const double  color[3]
)

Set/get the color for a block given its flat index.

◆ SetBlockColor() [2/2]

void vtkCompositePolyDataMapper::SetBlockColor ( unsigned int  index,
double  r,
double  g,
double  b
)
inline

Set/get the color for a block given its flat index.

Definition at line 128 of file vtkCompositePolyDataMapper.h.

◆ GetBlockColor() [1/2]

double* vtkCompositePolyDataMapper::GetBlockColor ( unsigned int  index)

Set/get the color for a block given its flat index.

◆ GetBlockColor() [2/2]

void vtkCompositePolyDataMapper::GetBlockColor ( unsigned int  index,
double  color[3]
)

Set/get the color for a block given its flat index.

◆ RemoveBlockColor()

void vtkCompositePolyDataMapper::RemoveBlockColor ( unsigned int  index)

Set/get the color for a block given its flat index.

◆ RemoveBlockColors()

void vtkCompositePolyDataMapper::RemoveBlockColors ( )

Set/get the color for a block given its flat index.

◆ SetBlockOpacity()

void vtkCompositePolyDataMapper::SetBlockOpacity ( unsigned int  index,
double  opacity
)

Set/get the opacity for a block given its flat index.

◆ GetBlockOpacity()

double vtkCompositePolyDataMapper::GetBlockOpacity ( unsigned int  index)

Set/get the opacity for a block given its flat index.

◆ RemoveBlockOpacity()

void vtkCompositePolyDataMapper::RemoveBlockOpacity ( unsigned int  index)

Set/get the opacity for a block given its flat index.

◆ RemoveBlockOpacities()

void vtkCompositePolyDataMapper::RemoveBlockOpacities ( )

Set/get the opacity for a block given its flat index.

◆ SetBlockScalarMode()

void vtkCompositePolyDataMapper::SetBlockScalarMode ( unsigned int  index,
int  value
)

◆ GetBlockScalarMode()

int vtkCompositePolyDataMapper::GetBlockScalarMode ( unsigned int  index)

◆ RemoveBlockScalarMode()

void vtkCompositePolyDataMapper::RemoveBlockScalarMode ( unsigned int  index)

◆ RemoveBlockScalarModes()

void vtkCompositePolyDataMapper::RemoveBlockScalarModes ( )

◆ SetBlockArrayAccessMode()

void vtkCompositePolyDataMapper::SetBlockArrayAccessMode ( unsigned int  index,
int  value
)

◆ GetBlockArrayAccessMode()

int vtkCompositePolyDataMapper::GetBlockArrayAccessMode ( unsigned int  index)

◆ RemoveBlockArrayAccessMode()

void vtkCompositePolyDataMapper::RemoveBlockArrayAccessMode ( unsigned int  index)

◆ RemoveBlockArrayAccessModes()

void vtkCompositePolyDataMapper::RemoveBlockArrayAccessModes ( )

◆ SetBlockArrayComponent()

void vtkCompositePolyDataMapper::SetBlockArrayComponent ( unsigned int  index,
int  value
)

◆ GetBlockArrayComponent()

int vtkCompositePolyDataMapper::GetBlockArrayComponent ( unsigned int  index)

◆ RemoveBlockArrayComponent()

void vtkCompositePolyDataMapper::RemoveBlockArrayComponent ( unsigned int  index)

◆ RemoveBlockArrayComponents()

void vtkCompositePolyDataMapper::RemoveBlockArrayComponents ( )

◆ SetBlockArrayId()

void vtkCompositePolyDataMapper::SetBlockArrayId ( unsigned int  index,
int  value
)

◆ GetBlockArrayId()

int vtkCompositePolyDataMapper::GetBlockArrayId ( unsigned int  index)

◆ RemoveBlockArrayId()

void vtkCompositePolyDataMapper::RemoveBlockArrayId ( unsigned int  index)

◆ RemoveBlockArrayIds()

void vtkCompositePolyDataMapper::RemoveBlockArrayIds ( )

◆ SetBlockArrayName()

void vtkCompositePolyDataMapper::SetBlockArrayName ( unsigned int  index,
const std::string &  value
)

◆ GetBlockArrayName()

std::string vtkCompositePolyDataMapper::GetBlockArrayName ( unsigned int  index)

◆ RemoveBlockArrayName()

void vtkCompositePolyDataMapper::RemoveBlockArrayName ( unsigned int  index)

◆ RemoveBlockArrayNames()

void vtkCompositePolyDataMapper::RemoveBlockArrayNames ( )

◆ SetBlockFieldDataTupleId()

void vtkCompositePolyDataMapper::SetBlockFieldDataTupleId ( unsigned int  index,
vtkIdType  value
)

◆ GetBlockFieldDataTupleId()

vtkIdType vtkCompositePolyDataMapper::GetBlockFieldDataTupleId ( unsigned int  index)

◆ RemoveBlockFieldDataTupleId()

void vtkCompositePolyDataMapper::RemoveBlockFieldDataTupleId ( unsigned int  index)

◆ RemoveBlockFieldDataTupleIds()

void vtkCompositePolyDataMapper::RemoveBlockFieldDataTupleIds ( )

◆ SetColorMissingArraysWithNanColor()

virtual void vtkCompositePolyDataMapper::SetColorMissingArraysWithNanColor ( bool  )
virtual

If the current 'color by' array is missing on some datasets, color these dataset by the LookupTable's NaN color, if the lookup table supports it.

Default is false.

◆ GetColorMissingArraysWithNanColor()

virtual bool vtkCompositePolyDataMapper::GetColorMissingArraysWithNanColor ( )
virtual

If the current 'color by' array is missing on some datasets, color these dataset by the LookupTable's NaN color, if the lookup table supports it.

Default is false.

◆ ColorMissingArraysWithNanColorOn()

virtual void vtkCompositePolyDataMapper::ColorMissingArraysWithNanColorOn ( )
virtual

If the current 'color by' array is missing on some datasets, color these dataset by the LookupTable's NaN color, if the lookup table supports it.

Default is false.

◆ ColorMissingArraysWithNanColorOff()

virtual void vtkCompositePolyDataMapper::ColorMissingArraysWithNanColorOff ( )
virtual

If the current 'color by' array is missing on some datasets, color these dataset by the LookupTable's NaN color, if the lookup table supports it.

Default is false.

◆ SetInputArrayToProcess() [1/7]

void vtkCompositePolyDataMapper::SetInputArrayToProcess ( int  idx,
int  port,
int  connection,
int  fieldAssociation,
const char *  name
)
overridevirtual

Call SetInputArrayToProcess on helpers.

Reimplemented from vtkAlgorithm.

◆ SetInputArrayToProcess() [2/7]

void vtkCompositePolyDataMapper::SetInputArrayToProcess ( int  idx,
int  port,
int  connection,
int  fieldAssociation,
int  fieldAttributeType
)
overridevirtual

Call SetInputArrayToProcess on helpers.

Reimplemented from vtkAlgorithm.

◆ SetInputArrayToProcess() [3/7]

void vtkCompositePolyDataMapper::SetInputArrayToProcess ( int  idx,
vtkInformation info
)
overridevirtual

Call SetInputArrayToProcess on helpers.

Reimplemented from vtkAlgorithm.

◆ GetRenderedList()

std::vector<vtkPolyData*> vtkCompositePolyDataMapper::GetRenderedList ( )

Accessor to the ordered list of PolyData that we last drew.

◆ ProcessSelectorPixelBuffers()

void vtkCompositePolyDataMapper::ProcessSelectorPixelBuffers ( vtkHardwareSelector sel,
std::vector< unsigned int > &  pixeloffsets,
vtkProp prop
)
overridevirtual

allows a mapper to update a selections color buffers Called from a prop which in turn is called from the selector

Reimplemented from vtkMapper.

◆ SetVBOShiftScaleMethod()

void vtkCompositePolyDataMapper::SetVBOShiftScaleMethod ( int  method)
overridevirtual

A convenience method for enabling/disabling the VBO's shift+scale transform.

Reimplemented from vtkPolyDataMapper.

◆ SetPauseShiftScale()

void vtkCompositePolyDataMapper::SetPauseShiftScale ( bool  pauseShiftScale)
overridevirtual

Pause updates of shift-scale parameters based on camera position.

This override passes the information to all instances in Helpers .

Reimplemented from vtkPolyDataMapper.

◆ GetMTime()

vtkMTimeType vtkCompositePolyDataMapper::GetMTime ( )
overridevirtual

Overridden to include vtkCompositeDataDisplayAttributes' mtime.

Reimplemented from vtkAbstractMapper.

◆ SetPointIdArrayName()

virtual void vtkCompositePolyDataMapper::SetPointIdArrayName ( const char *  )
virtual

By default, this class uses the dataset's point and cell ids during rendering.

However, one can override those by specifying cell and point data arrays to use instead. Currently, only vtkIdType array is supported. Set to NULL string (default) to use the point ids instead.

◆ GetPointIdArrayName()

virtual char* vtkCompositePolyDataMapper::GetPointIdArrayName ( )
virtual

By default, this class uses the dataset's point and cell ids during rendering.

However, one can override those by specifying cell and point data arrays to use instead. Currently, only vtkIdType array is supported. Set to NULL string (default) to use the point ids instead.

◆ SetCellIdArrayName()

virtual void vtkCompositePolyDataMapper::SetCellIdArrayName ( const char *  )
virtual

By default, this class uses the dataset's point and cell ids during rendering.

However, one can override those by specifying cell and point data arrays to use instead. Currently, only vtkIdType array is supported. Set to NULL string (default) to use the point ids instead.

◆ GetCellIdArrayName()

virtual char* vtkCompositePolyDataMapper::GetCellIdArrayName ( )
virtual

By default, this class uses the dataset's point and cell ids during rendering.

However, one can override those by specifying cell and point data arrays to use instead. Currently, only vtkIdType array is supported. Set to NULL string (default) to use the point ids instead.

◆ SetProcessIdArrayName()

virtual void vtkCompositePolyDataMapper::SetProcessIdArrayName ( const char *  )
virtual

If this class should override the process id using a data-array, set this variable to the name of the array to use.

It must be a point-array.

◆ GetProcessIdArrayName()

virtual char* vtkCompositePolyDataMapper::GetProcessIdArrayName ( )
virtual

If this class should override the process id using a data-array, set this variable to the name of the array to use.

It must be a point-array.

◆ SetCompositeIdArrayName()

virtual void vtkCompositePolyDataMapper::SetCompositeIdArrayName ( const char *  )
virtual

Generally, this class can render the composite id when iterating over composite datasets.

However in some cases (as in AMR), the rendered structure may not correspond to the input data, in which case we need to provide a cell array that can be used to render in the composite id in selection passes. Set to NULL (default) to not override the composite id color set by vtkCompositePainter if any. The array MUST be a cell array and of type vtkUnsignedIntArray.

◆ GetCompositeIdArrayName()

virtual char* vtkCompositePolyDataMapper::GetCompositeIdArrayName ( )
virtual

Generally, this class can render the composite id when iterating over composite datasets.

However in some cases (as in AMR), the rendered structure may not correspond to the input data, in which case we need to provide a cell array that can be used to render in the composite id in selection passes. Set to NULL (default) to not override the composite id color set by vtkCompositePainter if any. The array MUST be a cell array and of type vtkUnsignedIntArray.

◆ InsertPolyData()

MapperHashType vtkCompositePolyDataMapper::InsertPolyData ( vtkPolyData polydata,
const unsigned int &  flatIndex
)
protected

◆ CreateDefaultExecutive()

vtkExecutive* vtkCompositePolyDataMapper::CreateDefaultExecutive ( )
overrideprotectedvirtual

We need to override this method because the standard streaming demand driven pipeline is not what we want - we are expecting hierarchical data as input.

Reimplemented from vtkAlgorithm.

◆ FillInputPortInformation()

int vtkCompositePolyDataMapper::FillInputPortInformation ( int  port,
vtkInformation info
)
overrideprotectedvirtual

Need to define the type of data handled by this mapper.

Reimplemented from vtkAlgorithm.

◆ CreateADelegator()

virtual vtkCompositePolyDataMapperDelegator* vtkCompositePolyDataMapper::CreateADelegator ( )
protectedvirtual

This is the build method for creating the delegator.

A delegator has definitions for a single batch element and methods to insert, get, clear a whole batch. The delegator also provides the underlying mapper through delegator->GetDelegate()

Reimplemented in vtkCompositeSurfaceLICMapper.

◆ PreRender()

virtual void vtkCompositePolyDataMapper::PreRender ( const std::vector< vtkSmartPointer< vtkCompositePolyDataMapperDelegator >> &  ,
vtkRenderer ,
vtkActor
)
inlineprotectedvirtual

Invoked just before all delegators render their datasets.

You may access the built delegators this way to do custom initialization that is specific to the domain of your custom delegator.

Definition at line 332 of file vtkCompositePolyDataMapper.h.

◆ PostRender()

virtual void vtkCompositePolyDataMapper::PostRender ( const std::vector< vtkSmartPointer< vtkCompositePolyDataMapperDelegator >> &  ,
vtkRenderer ,
vtkActor
)
inlineprotectedvirtual

Invoked just after all delegators render their datasets.

You may access the built delegators this way to performa a finalize action.

Definition at line 341 of file vtkCompositePolyDataMapper.h.

◆ GenerateHash()

vtkPolyDataMapper::MapperHashType vtkCompositePolyDataMapper::GenerateHash ( vtkPolyData polydata)
overrideprotectedvirtual

Creates an empty polydata mapper and asks the mapper to hash the polydata.

Reimplemented from vtkPolyDataMapper.

◆ MakeAnIterator()

virtual vtkDataObjectTreeIterator* vtkCompositePolyDataMapper::MakeAnIterator ( vtkCompositeDataSet dataset)
protectedvirtual

Initialize an iterator for the composite dataset.

◆ ComputeBounds()

void vtkCompositePolyDataMapper::ComputeBounds ( )
overrideprotectedvirtual

Need to loop over the hierarchy to compute bounds.

Reimplemented from vtkPolyDataMapper.

◆ RecursiveHasTranslucentGeometry()

bool vtkCompositePolyDataMapper::RecursiveHasTranslucentGeometry ( vtkDataObject dobj,
unsigned int &  flat_index
)
protected

◆ BuildRenderValues()

void vtkCompositePolyDataMapper::BuildRenderValues ( vtkRenderer renderer,
vtkActor actor,
vtkDataObject dobj,
unsigned int &  flat_index
)
protected

◆ SetInputArrayToProcess() [4/7]

virtual void vtkAlgorithm::SetInputArrayToProcess

Call SetInputArrayToProcess on helpers.

◆ SetInputArrayToProcess() [5/7]

virtual void vtkAlgorithm::SetInputArrayToProcess

Call SetInputArrayToProcess on helpers.

◆ SetInputArrayToProcess() [6/7]

virtual void vtkAlgorithm::SetInputArrayToProcess

Call SetInputArrayToProcess on helpers.

◆ SetInputArrayToProcess() [7/7]

virtual void vtkAlgorithm::SetInputArrayToProcess

Call SetInputArrayToProcess on helpers.

Member Data Documentation

◆ PrototypeMapper

vtkNew<vtkPolyDataMapper> vtkCompositePolyDataMapper::PrototypeMapper
protected

A prototype of the object factory override mapper.

This prototype is reused to hash multiple polydata instead of creating a new mapper every single time a hash needs to be computed.

Definition at line 371 of file vtkCompositePolyDataMapper.h.

◆ CompositeAttributes

vtkSmartPointer<vtkCompositeDataDisplayAttributes> vtkCompositePolyDataMapper::CompositeAttributes
protected

Composite data set attributes.

Definition at line 376 of file vtkCompositePolyDataMapper.h.

◆ ColorMissingArraysWithNanColor

bool vtkCompositePolyDataMapper::ColorMissingArraysWithNanColor = false
protected

If the current 'color by' array is missing on some datasets, color these dataset by the LookupTable's NaN color, if the lookup table supports it.

Definition at line 382 of file vtkCompositePolyDataMapper.h.

◆ BoundsMTime

vtkTimeStamp vtkCompositePolyDataMapper::BoundsMTime
protected

Time stamp for computation of bounds.

Definition at line 387 of file vtkCompositePolyDataMapper.h.

◆ PointIdArrayName

char* vtkCompositePolyDataMapper::PointIdArrayName = nullptr
protected

Definition at line 390 of file vtkCompositePolyDataMapper.h.

◆ CellIdArrayName

char* vtkCompositePolyDataMapper::CellIdArrayName = nullptr
protected

Definition at line 391 of file vtkCompositePolyDataMapper.h.

◆ ProcessIdArrayName

char* vtkCompositePolyDataMapper::ProcessIdArrayName = nullptr
protected

Definition at line 392 of file vtkCompositePolyDataMapper.h.

◆ CompositeIdArrayName

char* vtkCompositePolyDataMapper::CompositeIdArrayName = nullptr
protected

Definition at line 393 of file vtkCompositePolyDataMapper.h.

◆ TranslucentState

vtkStateStorage vtkCompositePolyDataMapper::TranslucentState
protected

Definition at line 395 of file vtkCompositePolyDataMapper.h.

◆ HasTranslucentGeometry

bool vtkCompositePolyDataMapper::HasTranslucentGeometry = false
protected

Definition at line 396 of file vtkCompositePolyDataMapper.h.

◆ RenderValuesState

vtkStateStorage vtkCompositePolyDataMapper::RenderValuesState
protected

Definition at line 397 of file vtkCompositePolyDataMapper.h.

◆ TempState

vtkStateStorage vtkCompositePolyDataMapper::TempState
protected

Definition at line 398 of file vtkCompositePolyDataMapper.h.

◆ DelegatorMTime

vtkTimeStamp vtkCompositePolyDataMapper::DelegatorMTime
protected

Definition at line 399 of file vtkCompositePolyDataMapper.h.


The documentation for this class was generated from the following file:
