represent a user defined handle geometry in 3D space More...
#include <vtkPolygonalHandleRepresentation3D.h>
Public Member Functions | |
| virtual void | SetWorldPosition (double p[3]) |
| virtual void | SetOffset (double, double, double) |
| virtual void | SetOffset (double[3]) |
| virtual double * | GetOffset () |
| virtual void | GetOffset (double &, double &, double &) |
| virtual void | GetOffset (double[3]) |
Static Public Member Functions | |
| static vtkPolygonalHandleRepresentation3D * | New () |
Protected Member Functions | |
| vtkPolygonalHandleRepresentation3D () | |
| ~vtkPolygonalHandleRepresentation3D () | |
Protected Attributes | |
| double | Offset [3] |
| typedef vtkAbstractPolygonalHandleRepresentation3D | Superclass |
| static int | IsTypeOf (const char *type) |
| static vtkPolygonalHandleRepresentation3D * | SafeDownCast (vtkObject *o) |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
Detailed Description
represent a user defined handle geometry in 3D space
This class serves as the geometrical representation of a vtkHandleWidget. The handle can be represented by an arbitrary polygonal data (vtkPolyData), set via SetHandle(vtkPolyData *). The actual position of the handle will be initially assumed to be (0,0,0). You can specify an offset from this position if desired.
Definition at line 35 of file vtkPolygonalHandleRepresentation3D.h.
Member Typedef Documentation
Standard methods for instances of this class.
Reimplemented from vtkAbstractPolygonalHandleRepresentation3D.
Reimplemented in vtkFixedSizeHandleRepresentation3D.
Definition at line 45 of file vtkPolygonalHandleRepresentation3D.h.
Constructor & Destructor Documentation
| vtkPolygonalHandleRepresentation3D::vtkPolygonalHandleRepresentation3D | ( | ) | [protected] |
| vtkPolygonalHandleRepresentation3D::~vtkPolygonalHandleRepresentation3D | ( | ) | [inline, protected] |
Definition at line 61 of file vtkPolygonalHandleRepresentation3D.h.
Member Function Documentation
| static vtkPolygonalHandleRepresentation3D* vtkPolygonalHandleRepresentation3D::New | ( | ) | [static] |
Instantiate this class.
Reimplemented from vtkObject.
Reimplemented in vtkFixedSizeHandleRepresentation3D.
| virtual const char* vtkPolygonalHandleRepresentation3D::GetClassName | ( | ) | [virtual] |
Standard methods for instances of this class.
Reimplemented from vtkAbstractPolygonalHandleRepresentation3D.
Reimplemented in vtkFixedSizeHandleRepresentation3D.
| static int vtkPolygonalHandleRepresentation3D::IsTypeOf | ( | const char * | type | ) | [static] |
Standard methods for instances of this class.
Reimplemented from vtkAbstractPolygonalHandleRepresentation3D.
Reimplemented in vtkFixedSizeHandleRepresentation3D.
| virtual int vtkPolygonalHandleRepresentation3D::IsA | ( | const char * | type | ) | [virtual] |
Standard methods for instances of this class.
Reimplemented from vtkAbstractPolygonalHandleRepresentation3D.
Reimplemented in vtkFixedSizeHandleRepresentation3D.
| static vtkPolygonalHandleRepresentation3D* vtkPolygonalHandleRepresentation3D::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Standard methods for instances of this class.
Reimplemented from vtkAbstractPolygonalHandleRepresentation3D.
Reimplemented in vtkFixedSizeHandleRepresentation3D.
| void vtkPolygonalHandleRepresentation3D::PrintSelf | ( | ostream & | os, |
| vtkIndent | indent | ||
| ) | [virtual] |
Standard methods for instances of this class.
Reimplemented from vtkAbstractPolygonalHandleRepresentation3D.
Reimplemented in vtkFixedSizeHandleRepresentation3D.
| virtual void vtkPolygonalHandleRepresentation3D::SetWorldPosition | ( | double | p[3] | ) | [virtual] |
Set the position of the point in world and display coordinates.
Reimplemented from vtkAbstractPolygonalHandleRepresentation3D.
Set/get the offset of the handle position with respect to the handle center, assumed to be the origin.
| virtual void vtkPolygonalHandleRepresentation3D::SetOffset | ( | double | [3] | ) | [virtual] |
Set/get the offset of the handle position with respect to the handle center, assumed to be the origin.
| virtual double* vtkPolygonalHandleRepresentation3D::GetOffset | ( | ) | [virtual] |
Set/get the offset of the handle position with respect to the handle center, assumed to be the origin.
| virtual void vtkPolygonalHandleRepresentation3D::GetOffset | ( | double & | , |
| double & | , | ||
| double & | |||
| ) | [virtual] |
Set/get the offset of the handle position with respect to the handle center, assumed to be the origin.
| virtual void vtkPolygonalHandleRepresentation3D::GetOffset | ( | double | [3] | ) | [virtual] |
Set/get the offset of the handle position with respect to the handle center, assumed to be the origin.
Member Data Documentation
double vtkPolygonalHandleRepresentation3D::Offset[3] [protected] |
Definition at line 61 of file vtkPolygonalHandleRepresentation3D.h.
The documentation for this class was generated from the following file:
- dox/Widgets/vtkPolygonalHandleRepresentation3D.h
