#include <vtkInterpolatedVelocityField.h>
vtkInterpolatedVelocityField acts as a continuous velocity field by performing cell interpolation on the underlying vtkDataSet. This is a concrete sub-class of vtkFunctionSet with NumberOfIndependentVariables = 4 (x,y,z,t) and NumberOfFunctions = 3 (u,v,w). Normally, every time an evaluation is performed, the cell which contains the point (x,y,z) has to be found by calling FindCell. This is a computationally expensive operation. In certain cases, the cell search can be avoided or shortened by providing a guess for the cell id. For example, in streamline integration, the next evaluation is usually in the same or a neighbour cell. For this reason, vtkInterpolatedVelocityField stores the last cell id. If caching is turned on, it uses this id as the starting point.
Definition at line 52 of file vtkInterpolatedVelocityField.h.
Public Types | |
typedef vtkFunctionSet | Superclass |
Public Member Functions | |
virtual const char * | GetClassName () |
virtual int | IsA (const char *type) |
virtual void | PrintSelf (ostream &os, vtkIndent indent) |
virtual int | FunctionValues (double *x, double *f) |
virtual void | AddDataSet (vtkDataSet *dataset) |
void | ClearLastCellId () |
virtual void | CopyParameters (vtkInterpolatedVelocityField *from) |
virtual vtkIdType | GetLastCellId () |
void | SetLastCellId (vtkIdType c) |
void | SetLastCellId (vtkIdType c, int dataindex) |
int | GetLastWeights (double *w) |
int | GetLastLocalCoordinates (double pcoords[3]) |
virtual int | GetCaching () |
virtual void | SetCaching (int) |
virtual void | CachingOn () |
virtual void | CachingOff () |
virtual int | GetCacheHit () |
virtual int | GetCacheMiss () |
virtual char * | GetVectorsSelection () |
void | SelectVectors (const char *fieldName) |
virtual vtkDataSet * | GetLastDataSet () |
virtual int | GetLastDataSetIndex () |
Static Public Member Functions | |
static int | IsTypeOf (const char *type) |
static vtkInterpolatedVelocityField * | SafeDownCast (vtkObject *o) |
static vtkInterpolatedVelocityField * | New () |
Protected Member Functions | |
vtkInterpolatedVelocityField () | |
~vtkInterpolatedVelocityField () | |
virtual void | SetVectorsSelection (const char *) |
int | FunctionValues (vtkDataSet *ds, double *x, double *f) |
void | FastCompute (vtkDataArray *vectors, double f[3]) |
bool | InterpolatePoint (vtkPointData *outPD, vtkIdType outIndex) |
vtkGenericCell * | GetLastCell () |
Protected Attributes | |
vtkGenericCell * | GenCell |
vtkGenericCell * | Cell |
double * | Weights |
int | WeightsSize |
double | LastPCoords [3] |
vtkIdType | LastCellId |
int | CacheHit |
int | CacheMiss |
int | Caching |
int | LastDataSetIndex |
vtkDataSet * | LastDataSet |
char * | VectorsSelection |
vtkInterpolatedVelocityFieldDataSetsType * | DataSets |
Static Protected Attributes | |
static const double | TOLERANCE_SCALE |
Friends | |
class | vtkTemporalInterpolatedVelocityField |
vtkInterpolatedVelocityField::vtkInterpolatedVelocityField | ( | ) | [protected] |
vtkInterpolatedVelocityField::~vtkInterpolatedVelocityField | ( | ) | [protected] |
virtual const char* vtkInterpolatedVelocityField::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkFunctionSet.
static int vtkInterpolatedVelocityField::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkFunctionSet.
virtual int vtkInterpolatedVelocityField::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkFunctionSet.
static vtkInterpolatedVelocityField* vtkInterpolatedVelocityField::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkFunctionSet.
virtual void vtkInterpolatedVelocityField::PrintSelf | ( | ostream & | os, | |
vtkIndent | indent | |||
) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkFunctionSet.
static vtkInterpolatedVelocityField* vtkInterpolatedVelocityField::New | ( | ) | [static] |
Construct a vtkInterpolatedVelocityField with no initial data set. Caching is on. LastCellId is set to -1.
Reimplemented from vtkObject.
virtual int vtkInterpolatedVelocityField::FunctionValues | ( | double * | x, | |
double * | f | |||
) | [virtual] |
Evaluate the velocity field, f, at (x, y, z, t). For now, t is ignored.
Implements vtkFunctionSet.
virtual void vtkInterpolatedVelocityField::AddDataSet | ( | vtkDataSet * | dataset | ) | [virtual] |
Add a dataset used for the implicit function evaluation. If more than one dataset is added, the evaluation point is searched in all until a match is found. THIS FUNCTION DOES NOT CHANGE THE REFERENCE COUNT OF dataset FOR THREAD SAFETY REASONS.
virtual vtkIdType vtkInterpolatedVelocityField::GetLastCellId | ( | ) | [virtual] |
Return the cell id cached from last evaluation.
void vtkInterpolatedVelocityField::SetLastCellId | ( | vtkIdType | c | ) | [inline] |
Return the cell id cached from last evaluation.
Definition at line 75 of file vtkInterpolatedVelocityField.h.
void vtkInterpolatedVelocityField::SetLastCellId | ( | vtkIdType | c, | |
int | dataindex | |||
) |
Return the cell id cached from last evaluation.
void vtkInterpolatedVelocityField::ClearLastCellId | ( | ) | [inline] |
Set the last cell id to -1 so that the next search does not start from the previous cell
Definition at line 82 of file vtkInterpolatedVelocityField.h.
int vtkInterpolatedVelocityField::GetLastWeights | ( | double * | w | ) |
Returns the interpolation weights cached from last evaluation if the cached cell is valid (returns 1). Otherwise, it does not change w and returns 0.
int vtkInterpolatedVelocityField::GetLastLocalCoordinates | ( | double | pcoords[3] | ) |
Returns the interpolation weights cached from last evaluation if the cached cell is valid (returns 1). Otherwise, it does not change w and returns 0.
virtual int vtkInterpolatedVelocityField::GetCaching | ( | ) | [virtual] |
Turn caching on/off.
virtual void vtkInterpolatedVelocityField::SetCaching | ( | int | ) | [virtual] |
Turn caching on/off.
virtual void vtkInterpolatedVelocityField::CachingOn | ( | ) | [virtual] |
Turn caching on/off.
virtual void vtkInterpolatedVelocityField::CachingOff | ( | ) | [virtual] |
Turn caching on/off.
virtual int vtkInterpolatedVelocityField::GetCacheHit | ( | ) | [virtual] |
Caching statistics.
virtual int vtkInterpolatedVelocityField::GetCacheMiss | ( | ) | [virtual] |
Caching statistics.
virtual char* vtkInterpolatedVelocityField::GetVectorsSelection | ( | ) | [virtual] |
If you want to work with an arbitrary vector array, then set its name here. By default this in NULL and the filter will use the active vector array.
void vtkInterpolatedVelocityField::SelectVectors | ( | const char * | fieldName | ) | [inline] |
If you want to work with an arbitrary vector array, then set its name here. By default this in NULL and the filter will use the active vector array.
Definition at line 110 of file vtkInterpolatedVelocityField.h.
virtual vtkDataSet* vtkInterpolatedVelocityField::GetLastDataSet | ( | ) | [virtual] |
Returns the last dataset that was visited. Can be used as a first guess as to where the next point will be as well as to avoid searching through all datasets to get more information about the point. When setting the last dataset, you must be very careful no reference counting or checks are performed the feature is intended only to be used by custom interpolators which cache datasets independently
virtual int vtkInterpolatedVelocityField::GetLastDataSetIndex | ( | ) | [virtual] |
Returns the last dataset that was visited. Can be used as a first guess as to where the next point will be as well as to avoid searching through all datasets to get more information about the point. When setting the last dataset, you must be very careful no reference counting or checks are performed the feature is intended only to be used by custom interpolators which cache datasets independently
virtual void vtkInterpolatedVelocityField::CopyParameters | ( | vtkInterpolatedVelocityField * | from | ) | [virtual] |
Copy the user set parameters from source. This copies the Caching parameters. Sub-classes can add more after chaining.
virtual void vtkInterpolatedVelocityField::SetVectorsSelection | ( | const char * | ) | [protected, virtual] |
int vtkInterpolatedVelocityField::FunctionValues | ( | vtkDataSet * | ds, | |
double * | x, | |||
double * | f | |||
) | [protected] |
void vtkInterpolatedVelocityField::FastCompute | ( | vtkDataArray * | vectors, | |
double | f[3] | |||
) | [protected] |
If all weights have been computed (parametric coords etc all valid) then we can quickly interpolate a scalar/vector using the known weights and the generic cell which has been stored. This function is primarily reserved for use by vtkTemporalInterpolatedVelocityField
bool vtkInterpolatedVelocityField::InterpolatePoint | ( | vtkPointData * | outPD, | |
vtkIdType | outIndex | |||
) | [protected] |
If all weights have been computed (parametric coords etc all valid) then we can quickly interpolate a scalar/vector using the known weights and the generic cell which has been stored. This function is primarily reserved for use by vtkTemporalInterpolatedVelocityField
vtkGenericCell* vtkInterpolatedVelocityField::GetLastCell | ( | ) | [protected] |
If all weights have been computed (parametric coords etc all valid) then we can quickly interpolate a scalar/vector using the known weights and the generic cell which has been stored. This function is primarily reserved for use by vtkTemporalInterpolatedVelocityField
friend class vtkTemporalInterpolatedVelocityField [friend] |
Definition at line 154 of file vtkInterpolatedVelocityField.h.
vtkGenericCell* vtkInterpolatedVelocityField::GenCell [protected] |
Definition at line 134 of file vtkInterpolatedVelocityField.h.
vtkGenericCell* vtkInterpolatedVelocityField::Cell [protected] |
Definition at line 135 of file vtkInterpolatedVelocityField.h.
double* vtkInterpolatedVelocityField::Weights [protected] |
Definition at line 136 of file vtkInterpolatedVelocityField.h.
int vtkInterpolatedVelocityField::WeightsSize [protected] |
Definition at line 137 of file vtkInterpolatedVelocityField.h.
double vtkInterpolatedVelocityField::LastPCoords[3] [protected] |
Definition at line 138 of file vtkInterpolatedVelocityField.h.
vtkIdType vtkInterpolatedVelocityField::LastCellId [protected] |
Definition at line 139 of file vtkInterpolatedVelocityField.h.
int vtkInterpolatedVelocityField::CacheHit [protected] |
Definition at line 140 of file vtkInterpolatedVelocityField.h.
int vtkInterpolatedVelocityField::CacheMiss [protected] |
Definition at line 141 of file vtkInterpolatedVelocityField.h.
int vtkInterpolatedVelocityField::Caching [protected] |
Definition at line 142 of file vtkInterpolatedVelocityField.h.
int vtkInterpolatedVelocityField::LastDataSetIndex [protected] |
Definition at line 143 of file vtkInterpolatedVelocityField.h.
vtkDataSet* vtkInterpolatedVelocityField::LastDataSet [protected] |
Definition at line 145 of file vtkInterpolatedVelocityField.h.
char* vtkInterpolatedVelocityField::VectorsSelection [protected] |
Definition at line 147 of file vtkInterpolatedVelocityField.h.
vtkInterpolatedVelocityFieldDataSetsType* vtkInterpolatedVelocityField::DataSets [protected] |
Definition at line 150 of file vtkInterpolatedVelocityField.h.
const double vtkInterpolatedVelocityField::TOLERANCE_SCALE [static, protected] |
Definition at line 167 of file vtkInterpolatedVelocityField.h.
