vtkParallelRenderManager Class Reference
#include <vtkParallelRenderManager.h>
Detailed Description
An object to control parallel rendering.vtkParallelRenderManager operates in multiple processes. It provides proper renderers and render windows for performing the parallel rendering correctly. It can also attach itself to render windows and propagate rendering events and camera views.
This class is based on the vtkCompositeManager class, except that it can handle any type of parallel rendering.
- Attention:
- Many parallel rendering schemes do not correctly handle transparency. Unless otherwise documented, assume a sub class does not.
- Todo:
- Synchronization/barrier primitives.
- Todo:
- Query ranges of scalar values of objects in addition to the boundry in three-space
Definition at line 65 of file vtkParallelRenderManager.h.
Member Typedef Documentation
Reimplemented from vtkObject.
Reimplemented in vtkCompositeRenderManager.
Definition at line 68 of file vtkParallelRenderManager.h.
Member Enumeration Documentation
| anonymous enum |
- Enumerator:
-
RENDER_RMI_TAG COMPUTE_VISIBLE_PROP_BOUNDS_RMI_TAG WIN_INFO_INT_TAG WIN_INFO_DOUBLE_TAG REN_INFO_INT_TAG REN_INFO_DOUBLE_TAG LIGHT_INFO_DOUBLE_TAG REN_ID_TAG BOUNDS_TAG
Definition at line 350 of file vtkParallelRenderManager.h.
Constructor & Destructor Documentation
| vtkParallelRenderManager::vtkParallelRenderManager | ( | ) | [protected] |
| vtkParallelRenderManager::~vtkParallelRenderManager | ( | ) | [protected] |
Member Function Documentation
| virtual const char* vtkParallelRenderManager::GetClassName | ( | ) | [virtual] |
| static int vtkParallelRenderManager::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkObject.
Reimplemented in vtkCompositeRenderManager.
| virtual int vtkParallelRenderManager::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkObject.
Reimplemented in vtkCompositeRenderManager.
| static vtkParallelRenderManager* vtkParallelRenderManager::SafeDownCast | ( | vtkObject * | o | ) | [static] |
| virtual void vtkParallelRenderManager::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkObject.
Reimplemented in vtkCompositeRenderManager.
| virtual vtkRenderWindow* vtkParallelRenderManager::MakeRenderWindow | ( | ) | [virtual] |
Builds a vtkRenderWindow compatible with this render manager. The user program is responsible for registering the render window with the SetRenderWindow method and calling Delete. It is not advisable to use a parallel render manager with a render window that was not built with this method.
| virtual vtkRenderer* vtkParallelRenderManager::MakeRenderer | ( | ) | [virtual] |
Builds a vtkRenderer compatible with this render manager. (Should we also register it?) The user program is responsible for calling Delete. It is not advisable to use a parallel render manager with a renderer that was not built with this method.
| virtual vtkRenderWindow* vtkParallelRenderManager::GetRenderWindow | ( | ) | [virtual] |
Set/Get the RenderWindow to use for compositing. We add a start and end observer to the window.
| virtual void vtkParallelRenderManager::SetRenderWindow | ( | vtkRenderWindow * | renWin | ) | [virtual] |
Set/Get the RenderWindow to use for compositing. We add a start and end observer to the window.
| virtual vtkMultiProcessController* vtkParallelRenderManager::GetController | ( | ) | [virtual] |
Set/Get the vtkMultiProcessController which will handle communications for the parallel rendering.
| virtual void vtkParallelRenderManager::SetController | ( | vtkMultiProcessController * | controller | ) | [virtual] |
Set/Get the vtkMultiProcessController which will handle communications for the parallel rendering.
| virtual void vtkParallelRenderManager::InitializePieces | ( | ) | [virtual] |
This method sets the piece and number of pieces for each actor with a polydata mapper.
| virtual void vtkParallelRenderManager::InitializeOffScreen | ( | ) | [virtual] |
Make all rendering windows not viewable set as off screen rendering. To make all renderwindows on screen rendering again, call OffScreenRenderingOff on all the render windows. This class assumes the window on root node is the only one viewable. Subclasses should change this as necessary.
| virtual void vtkParallelRenderManager::StartInteractor | ( | ) | [virtual] |
Initializes the RMIs and then, if on root node, starts the interactor on the attached render window. Otherwise, starts processing RMIs. When the interactor returns, it breaks the RMI listening on all other processors.
| virtual void vtkParallelRenderManager::StartServices | ( | ) | [virtual] |
If on node other than root, starts serving RMI requests for parallel renders.
| virtual void vtkParallelRenderManager::StopServices | ( | ) | [virtual] |
If on root node, stops the RMI processing on all service nodes.
| virtual void vtkParallelRenderManager::StartRender | ( | ) | [virtual] |
Callbacks that initialize and finish rendering and other tasks.
| virtual void vtkParallelRenderManager::EndRender | ( | ) | [virtual] |
Callbacks that initialize and finish rendering and other tasks.
| virtual void vtkParallelRenderManager::SatelliteStartRender | ( | ) | [virtual] |
Callbacks that initialize and finish rendering and other tasks.
| virtual void vtkParallelRenderManager::SatelliteEndRender | ( | ) | [virtual] |
Callbacks that initialize and finish rendering and other tasks.
| virtual void vtkParallelRenderManager::RenderRMI | ( | ) | [virtual] |
Callbacks that initialize and finish rendering and other tasks.
| virtual void vtkParallelRenderManager::ResetCamera | ( | vtkRenderer * | ren | ) | [virtual] |
Callbacks that initialize and finish rendering and other tasks.
| virtual void vtkParallelRenderManager::ResetCameraClippingRange | ( | vtkRenderer * | ren | ) | [virtual] |
Callbacks that initialize and finish rendering and other tasks.
| virtual void vtkParallelRenderManager::ComputeVisiblePropBoundsRMI | ( | ) | [virtual] |
Callbacks that initialize and finish rendering and other tasks.
| virtual void vtkParallelRenderManager::InitializeRMIs | ( | ) | [virtual] |
| virtual void vtkParallelRenderManager::ResetAllCameras | ( | ) | [virtual] |
Resets the camera of each renderer contained in the RenderWindow. Should only be called in the "root" process, and all remote processes must be processing RMIs for this method to complete.
| virtual void vtkParallelRenderManager::ComputeVisiblePropBounds | ( | vtkRenderer * | ren, | |
| double | bounds[6] | |||
| ) | [virtual] |
Calculates the bounds by gathering information from all processes.
| virtual void vtkParallelRenderManager::SetParallelRendering | ( | int | ) | [virtual] |
Turns on/off parallel rendering. When on (the default) the object responds to render events of the attached window, propagates the render event to other processors, and otherwise enables the parallel rendering process.
| virtual int vtkParallelRenderManager::GetParallelRendering | ( | ) | [virtual] |
Turns on/off parallel rendering. When on (the default) the object responds to render events of the attached window, propagates the render event to other processors, and otherwise enables the parallel rendering process.
| virtual void vtkParallelRenderManager::ParallelRenderingOn | ( | ) | [virtual] |
Turns on/off parallel rendering. When on (the default) the object responds to render events of the attached window, propagates the render event to other processors, and otherwise enables the parallel rendering process.
| virtual void vtkParallelRenderManager::ParallelRenderingOff | ( | ) | [virtual] |
Turns on/off parallel rendering. When on (the default) the object responds to render events of the attached window, propagates the render event to other processors, and otherwise enables the parallel rendering process.
| virtual void vtkParallelRenderManager::SetRenderEventPropagation | ( | int | ) | [virtual] |
Turns on/off render event propagation. When on (the default) and ParallelRendering is on, process 0 will send an RMI call to all remote processes to perform a synchronized render. When off, render must be manually called on each process.
| virtual int vtkParallelRenderManager::GetRenderEventPropagation | ( | ) | [virtual] |
Turns on/off render event propagation. When on (the default) and ParallelRendering is on, process 0 will send an RMI call to all remote processes to perform a synchronized render. When off, render must be manually called on each process.
| virtual void vtkParallelRenderManager::RenderEventPropagationOn | ( | ) | [virtual] |
Turns on/off render event propagation. When on (the default) and ParallelRendering is on, process 0 will send an RMI call to all remote processes to perform a synchronized render. When off, render must be manually called on each process.
| virtual void vtkParallelRenderManager::RenderEventPropagationOff | ( | ) | [virtual] |
Turns on/off render event propagation. When on (the default) and ParallelRendering is on, process 0 will send an RMI call to all remote processes to perform a synchronized render. When off, render must be manually called on each process.
| virtual void vtkParallelRenderManager::SetUseCompositing | ( | int | ) | [virtual] |
This is used for tiled display rendering. When data has been duplicated on all processes, then we do not need to compositing. Cameras and renders are still propagated though.
| virtual int vtkParallelRenderManager::GetUseCompositing | ( | ) | [virtual] |
This is used for tiled display rendering. When data has been duplicated on all processes, then we do not need to compositing. Cameras and renders are still propagated though.
| virtual void vtkParallelRenderManager::UseCompositingOn | ( | ) | [virtual] |
This is used for tiled display rendering. When data has been duplicated on all processes, then we do not need to compositing. Cameras and renders are still propagated though.
| virtual void vtkParallelRenderManager::UseCompositingOff | ( | ) | [virtual] |
This is used for tiled display rendering. When data has been duplicated on all processes, then we do not need to compositing. Cameras and renders are still propagated though.
| virtual void vtkParallelRenderManager::SetImageReductionFactor | ( | double | factor | ) | [virtual] |
Set/Get the reduction factor (for sort-last based parallel renderers). The size of rendered image is divided by the reduction factor and then is blown up to the size of the current vtkRenderWindow. Setting higher reduction factors enables shorter image transfer times (which is often the bottleneck) but will greatly reduce image quality. A reduction factor of 2 or greater should only be used for intermediate images in interactive applications. A reduction factor of 1 (or less) will result in no change in image quality. A parallel render manager may ignore the image reduction factor if it will result in little or no performance enhancements (eg. it does not do image space manipulations).
| virtual double vtkParallelRenderManager::GetImageReductionFactor | ( | ) | [virtual] |
Set/Get the reduction factor (for sort-last based parallel renderers). The size of rendered image is divided by the reduction factor and then is blown up to the size of the current vtkRenderWindow. Setting higher reduction factors enables shorter image transfer times (which is often the bottleneck) but will greatly reduce image quality. A reduction factor of 2 or greater should only be used for intermediate images in interactive applications. A reduction factor of 1 (or less) will result in no change in image quality. A parallel render manager may ignore the image reduction factor if it will result in little or no performance enhancements (eg. it does not do image space manipulations).
| virtual void vtkParallelRenderManager::SetMaxImageReductionFactor | ( | double | ) | [virtual] |
| virtual double vtkParallelRenderManager::GetMaxImageReductionFactor | ( | ) | [virtual] |
| virtual void vtkParallelRenderManager::SetImageReductionFactorForUpdateRate | ( | double | DesiredUpdateRate | ) | [virtual] |
Sets the ReductionFactor based on the given desired update rate and the rendering metrics taken from the last time UpdateServerInfo was called. Note that if AutoReductionFactor is on, this function is called with the desired update rate of the render window automatically.
| virtual void vtkParallelRenderManager::SetAutoImageReductionFactor | ( | int | ) | [virtual] |
If on, the ReductionFactor is automatically adjusted to best meet the the DesiredUpdateRate in the current RenderWindow based on metrics from the last render.
| virtual int vtkParallelRenderManager::GetAutoImageReductionFactor | ( | ) | [virtual] |
If on, the ReductionFactor is automatically adjusted to best meet the the DesiredUpdateRate in the current RenderWindow based on metrics from the last render.
| virtual void vtkParallelRenderManager::AutoImageReductionFactorOn | ( | ) | [virtual] |
If on, the ReductionFactor is automatically adjusted to best meet the the DesiredUpdateRate in the current RenderWindow based on metrics from the last render.
| virtual void vtkParallelRenderManager::AutoImageReductionFactorOff | ( | ) | [virtual] |
If on, the ReductionFactor is automatically adjusted to best meet the the DesiredUpdateRate in the current RenderWindow based on metrics from the last render.
| virtual double vtkParallelRenderManager::GetRenderTime | ( | ) | [virtual] |
Get rendering metrics.
| virtual double vtkParallelRenderManager::GetImageProcessingTime | ( | ) | [virtual] |
Get rendering metrics.
Reimplemented in vtkCompositeRenderManager.
| virtual int vtkParallelRenderManager::GetSyncRenderWindowRenderers | ( | ) | [virtual] |
By default, the state of all renderers in the root's render window is propagated to the rest of the processes. In order for this to work, all render windows must have the same renderers in the same order. If this is not the case, you can turn off the SyncRenderWindowRenderers. When this flag is off, the list of renderers held by this parallel render manager (initially empty) is synced. You can modify the list of renderers with the AddRenderer, RemoveRenderer, and RemoveAllRenderers methods.
| virtual void vtkParallelRenderManager::SetSyncRenderWindowRenderers | ( | int | ) | [virtual] |
By default, the state of all renderers in the root's render window is propagated to the rest of the processes. In order for this to work, all render windows must have the same renderers in the same order. If this is not the case, you can turn off the SyncRenderWindowRenderers. When this flag is off, the list of renderers held by this parallel render manager (initially empty) is synced. You can modify the list of renderers with the AddRenderer, RemoveRenderer, and RemoveAllRenderers methods.
| virtual void vtkParallelRenderManager::SyncRenderWindowRenderersOn | ( | ) | [virtual] |
By default, the state of all renderers in the root's render window is propagated to the rest of the processes. In order for this to work, all render windows must have the same renderers in the same order. If this is not the case, you can turn off the SyncRenderWindowRenderers. When this flag is off, the list of renderers held by this parallel render manager (initially empty) is synced. You can modify the list of renderers with the AddRenderer, RemoveRenderer, and RemoveAllRenderers methods.
| virtual void vtkParallelRenderManager::SyncRenderWindowRenderersOff | ( | ) | [virtual] |
By default, the state of all renderers in the root's render window is propagated to the rest of the processes. In order for this to work, all render windows must have the same renderers in the same order. If this is not the case, you can turn off the SyncRenderWindowRenderers. When this flag is off, the list of renderers held by this parallel render manager (initially empty) is synced. You can modify the list of renderers with the AddRenderer, RemoveRenderer, and RemoveAllRenderers methods.
| virtual void vtkParallelRenderManager::AddRenderer | ( | vtkRenderer * | ) | [virtual] |
By default, the state of all renderers in the root's render window is propagated to the rest of the processes. In order for this to work, all render windows must have the same renderers in the same order. If this is not the case, you can turn off the SyncRenderWindowRenderers. When this flag is off, the list of renderers held by this parallel render manager (initially empty) is synced. You can modify the list of renderers with the AddRenderer, RemoveRenderer, and RemoveAllRenderers methods.
| virtual void vtkParallelRenderManager::RemoveRenderer | ( | vtkRenderer * | ) | [virtual] |
By default, the state of all renderers in the root's render window is propagated to the rest of the processes. In order for this to work, all render windows must have the same renderers in the same order. If this is not the case, you can turn off the SyncRenderWindowRenderers. When this flag is off, the list of renderers held by this parallel render manager (initially empty) is synced. You can modify the list of renderers with the AddRenderer, RemoveRenderer, and RemoveAllRenderers methods.
| virtual void vtkParallelRenderManager::RemoveAllRenderers | ( | ) | [virtual] |
By default, the state of all renderers in the root's render window is propagated to the rest of the processes. In order for this to work, all render windows must have the same renderers in the same order. If this is not the case, you can turn off the SyncRenderWindowRenderers. When this flag is off, the list of renderers held by this parallel render manager (initially empty) is synced. You can modify the list of renderers with the AddRenderer, RemoveRenderer, and RemoveAllRenderers methods.
| virtual void vtkParallelRenderManager::SetWriteBackImages | ( | int | ) | [virtual] |
If on (the default), the result of any image space manipulations are written back to the render window frame buffer. If off, the image stored in the frame buffer may not be correct. Either way, the correct frame buffer images may be read with vtkParallelRenderManager::GetPixelData. Turning WriteBackImages off may result in a speedup if the render window is not visible to the user and images are read back for further processing or transit.
| virtual int vtkParallelRenderManager::GetWriteBackImages | ( | ) | [virtual] |
If on (the default), the result of any image space manipulations are written back to the render window frame buffer. If off, the image stored in the frame buffer may not be correct. Either way, the correct frame buffer images may be read with vtkParallelRenderManager::GetPixelData. Turning WriteBackImages off may result in a speedup if the render window is not visible to the user and images are read back for further processing or transit.
| virtual void vtkParallelRenderManager::WriteBackImagesOn | ( | ) | [virtual] |
If on (the default), the result of any image space manipulations are written back to the render window frame buffer. If off, the image stored in the frame buffer may not be correct. Either way, the correct frame buffer images may be read with vtkParallelRenderManager::GetPixelData. Turning WriteBackImages off may result in a speedup if the render window is not visible to the user and images are read back for further processing or transit.
| virtual void vtkParallelRenderManager::WriteBackImagesOff | ( | ) | [virtual] |
If on (the default), the result of any image space manipulations are written back to the render window frame buffer. If off, the image stored in the frame buffer may not be correct. Either way, the correct frame buffer images may be read with vtkParallelRenderManager::GetPixelData. Turning WriteBackImages off may result in a speedup if the render window is not visible to the user and images are read back for further processing or transit.
| virtual void vtkParallelRenderManager::SetMagnifyImages | ( | int | ) | [virtual] |
If on (the default), when the ImageReductionFactor is greater than 1 and WriteBackImages is on, the image will be magnified to fill the entire render window.
| virtual int vtkParallelRenderManager::GetMagnifyImages | ( | ) | [virtual] |
If on (the default), when the ImageReductionFactor is greater than 1 and WriteBackImages is on, the image will be magnified to fill the entire render window.
| virtual void vtkParallelRenderManager::MagnifyImagesOn | ( | ) | [virtual] |
If on (the default), when the ImageReductionFactor is greater than 1 and WriteBackImages is on, the image will be magnified to fill the entire render window.
| virtual void vtkParallelRenderManager::MagnifyImagesOff | ( | ) | [virtual] |
If on (the default), when the ImageReductionFactor is greater than 1 and WriteBackImages is on, the image will be magnified to fill the entire render window.
| virtual void vtkParallelRenderManager::SetMagnifyImageMethod | ( | int | method | ) | [virtual] |
Sets the method used to magnify images. Nearest simply replicates each pixel enough times to fill the image. Linear performs linear interpolation between the pixels.
| virtual int vtkParallelRenderManager::GetMagnifyImageMethod | ( | ) | [virtual] |
Sets the method used to magnify images. Nearest simply replicates each pixel enough times to fill the image. Linear performs linear interpolation between the pixels.
| void vtkParallelRenderManager::SetMagnifyImageMethodToNearest | ( | ) | [inline] |
Sets the method used to magnify images. Nearest simply replicates each pixel enough times to fill the image. Linear performs linear interpolation between the pixels.
Definition at line 263 of file vtkParallelRenderManager.h.
| void vtkParallelRenderManager::SetMagnifyImageMethodToLinear | ( | ) | [inline] |
Sets the method used to magnify images. Nearest simply replicates each pixel enough times to fill the image. Linear performs linear interpolation between the pixels.
Definition at line 266 of file vtkParallelRenderManager.h.
| virtual void vtkParallelRenderManager::MagnifyImage | ( | vtkUnsignedCharArray * | fullImage, | |
| const int | fullImageSize[2], | |||
| vtkUnsignedCharArray * | reducedImage, | |||
| const int | reducedImageSize[2], | |||
| const int | fullImageViewport[4] = NULL, |
|||
| const int | reducedImageViewport[4] = NULL | |||
| ) | [virtual] |
Convenience functions for magnifying images.
| static void vtkParallelRenderManager::MagnifyImageNearest | ( | vtkUnsignedCharArray * | fullImage, | |
| const int | fullImageSize[2], | |||
| vtkUnsignedCharArray * | reducedImage, | |||
| const int | reducedImageSize[2], | |||
| const int | fullImageViewport[4] = NULL, |
|||
| const int | reducedImageViewport[4] = NULL | |||
| ) | [static] |
Convenience functions for magnifying images.
| static void vtkParallelRenderManager::MagnifyImageLinear | ( | vtkUnsignedCharArray * | fullImage, | |
| const int | fullImageSize[2], | |||
| vtkUnsignedCharArray * | reducedImage, | |||
| const int | reducedImageSize[2], | |||
| const int | fullImageViewport[4] = NULL, |
|||
| const int | reducedImageViewport[4] = NULL | |||
| ) | [static] |
Convenience functions for magnifying images.
| virtual void vtkParallelRenderManager::GetPixelData | ( | vtkUnsignedCharArray * | data | ) | [virtual] |
The most appropriate way to retrieve full size image data after a render. Will work regardless of whether WriteBackImages or MagnifyImage is on or off. The data returned may be a shallow copy of an internal array. Therefore, the data may be invalid after the next render or if the ParallelRenderManager is destroyed.
| virtual void vtkParallelRenderManager::GetPixelData | ( | int | x1, | |
| int | y1, | |||
| int | x2, | |||
| int | y2, | |||
| vtkUnsignedCharArray * | data | |||
| ) | [virtual] |
The most appropriate way to retrieve full size image data after a render. Will work regardless of whether WriteBackImages or MagnifyImage is on or off. The data returned may be a shallow copy of an internal array. Therefore, the data may be invalid after the next render or if the ParallelRenderManager is destroyed.
| virtual void vtkParallelRenderManager::GetReducedPixelData | ( | vtkUnsignedCharArray * | data | ) | [virtual] |
The most appropriate way to retrieve reduced size image data after a render. Will work regardless of whether WriteBackImages or MagnifyImage is on or off. The data returned may be a shallow copy of an internal array. Therefore, the data may be invalid after the next render or if the ParallelRenderManager is destroyed.
| virtual void vtkParallelRenderManager::GetReducedPixelData | ( | int | x1, | |
| int | y1, | |||
| int | x2, | |||
| int | y2, | |||
| vtkUnsignedCharArray * | data | |||
| ) | [virtual] |
The most appropriate way to retrieve reduced size image data after a render. Will work regardless of whether WriteBackImages or MagnifyImage is on or off. The data returned may be a shallow copy of an internal array. Therefore, the data may be invalid after the next render or if the ParallelRenderManager is destroyed.
| virtual int* vtkParallelRenderManager::GetFullImageSize | ( | ) | [virtual] |
Returns the full image size calculated at the last render.
| virtual void vtkParallelRenderManager::GetFullImageSize | ( | int & | , | |
| int & | ||||
| ) | [virtual] |
Returns the full image size calculated at the last render.
| virtual void vtkParallelRenderManager::GetFullImageSize | ( | int | [2] | ) | [virtual] |
Returns the full image size calculated at the last render.
| virtual int* vtkParallelRenderManager::GetReducedImageSize | ( | ) | [virtual] |
Returns the full image size calculated at the last render.
| virtual void vtkParallelRenderManager::GetReducedImageSize | ( | int & | , | |
| int & | ||||
| ) | [virtual] |
Returns the full image size calculated at the last render.
| virtual void vtkParallelRenderManager::GetReducedImageSize | ( | int | [2] | ) | [virtual] |
Returns the full image size calculated at the last render.
| void vtkParallelRenderManager::TileWindows | ( | int | xsize, | |
| int | ysize, | |||
| int | nColumns | |||
| ) |
Given the x and y size of the render windows, reposition them in a tile of n columns.
| virtual void vtkParallelRenderManager::SetUseRGBA | ( | int | ) | [virtual] |
Get/Set if all Images must use RGBA instead of RGB. By default, this flag is on.
| virtual int vtkParallelRenderManager::GetUseRGBA | ( | ) | [virtual] |
Get/Set if all Images must use RGBA instead of RGB. By default, this flag is on.
| virtual void vtkParallelRenderManager::SetForceRenderWindowSize | ( | int | ) | [virtual] |
If ForceRenderWindowSize is set to true, the render manager will use the RenderWindowSize ivar instead of getting the size from the render window.
| virtual int vtkParallelRenderManager::GetForceRenderWindowSize | ( | ) | [virtual] |
If ForceRenderWindowSize is set to true, the render manager will use the RenderWindowSize ivar instead of getting the size from the render window.
| virtual void vtkParallelRenderManager::SetForcedRenderWindowSize | ( | int | , | |
| int | ||||
| ) | [virtual] |
If ForceRenderWindowSize is set to true, the render manager will use the Size ivar instead of getting the size from the render window.
| void vtkParallelRenderManager::SetForcedRenderWindowSize | ( | int | [2] | ) |
If ForceRenderWindowSize is set to true, the render manager will use the Size ivar instead of getting the size from the render window.
| virtual int* vtkParallelRenderManager::GetForcedRenderWindowSize | ( | ) | [virtual] |
If ForceRenderWindowSize is set to true, the render manager will use the Size ivar instead of getting the size from the render window.
| virtual void vtkParallelRenderManager::GetForcedRenderWindowSize | ( | int & | , | |
| int & | ||||
| ) | [virtual] |
If ForceRenderWindowSize is set to true, the render manager will use the Size ivar instead of getting the size from the render window.
| virtual void vtkParallelRenderManager::GetForcedRenderWindowSize | ( | int | [2] | ) | [virtual] |
If ForceRenderWindowSize is set to true, the render manager will use the Size ivar instead of getting the size from the render window.
| virtual void vtkParallelRenderManager::CheckForAbortRender | ( | ) | [inline, virtual] |
Definition at line 362 of file vtkParallelRenderManager.h.
| virtual int vtkParallelRenderManager::CheckForAbortComposite | ( | ) | [inline, virtual] |
Definition at line 363 of file vtkParallelRenderManager.h.
| virtual void vtkParallelRenderManager::StartService | ( | ) | [virtual] |
- Deprecated:
- Replaced by vtkParallelRenderManager::StartServices() as of VTK 5.0.
| virtual void vtkParallelRenderManager::SetUseBackBuffer | ( | int | ) | [virtual] |
The default is to allow the use of the back buffer for compositing. If set to false, this will prevent to manager from swapping buffers. This allows something else (for instance VisibleCellSelection) to control front/back buffer swapping.
| virtual int vtkParallelRenderManager::GetUseBackBuffer | ( | ) | [virtual] |
The default is to allow the use of the back buffer for compositing. If set to false, this will prevent to manager from swapping buffers. This allows something else (for instance VisibleCellSelection) to control front/back buffer swapping.
| virtual void vtkParallelRenderManager::UseBackBufferOn | ( | ) | [virtual] |
The default is to allow the use of the back buffer for compositing. If set to false, this will prevent to manager from swapping buffers. This allows something else (for instance VisibleCellSelection) to control front/back buffer swapping.
| virtual void vtkParallelRenderManager::UseBackBufferOff | ( | ) | [virtual] |
The default is to allow the use of the back buffer for compositing. If set to false, this will prevent to manager from swapping buffers. This allows something else (for instance VisibleCellSelection) to control front/back buffer swapping.
| virtual void vtkParallelRenderManager::SetSynchronizeTileProperties | ( | int | ) | [virtual] |
When set the render manager will synchronize the TileViewport and TileScale properties. This may not be desirable in cases where there's some other mechanism to set the tile dimensions eg. Tile displays.
| virtual int vtkParallelRenderManager::GetSynchronizeTileProperties | ( | ) | [virtual] |
When set the render manager will synchronize the TileViewport and TileScale properties. This may not be desirable in cases where there's some other mechanism to set the tile dimensions eg. Tile displays.
| virtual void vtkParallelRenderManager::SynchronizeTilePropertiesOn | ( | ) | [virtual] |
When set the render manager will synchronize the TileViewport and TileScale properties. This may not be desirable in cases where there's some other mechanism to set the tile dimensions eg. Tile displays.
| virtual void vtkParallelRenderManager::SynchronizeTilePropertiesOff | ( | ) | [virtual] |
When set the render manager will synchronize the TileViewport and TileScale properties. This may not be desirable in cases where there's some other mechanism to set the tile dimensions eg. Tile displays.
| virtual vtkRendererCollection* vtkParallelRenderManager::GetRenderers | ( | ) | [protected, virtual] |
| virtual void vtkParallelRenderManager::SendWindowInformation | ( | ) | [inline, protected, virtual] |
Used to synchronize rendering information per frame.
Definition at line 489 of file vtkParallelRenderManager.h.
| virtual void vtkParallelRenderManager::ReceiveWindowInformation | ( | ) | [inline, protected, virtual] |
Used to synchronize rendering information per frame.
Definition at line 490 of file vtkParallelRenderManager.h.
| virtual void vtkParallelRenderManager::SendRendererInformation | ( | vtkRenderer * | ) | [inline, protected, virtual] |
Used to synchronize rendering information per frame.
Definition at line 491 of file vtkParallelRenderManager.h.
| virtual void vtkParallelRenderManager::ReceiveRendererInformation | ( | vtkRenderer * | ) | [inline, protected, virtual] |
Used to synchronize rendering information per frame.
Definition at line 492 of file vtkParallelRenderManager.h.
| virtual void vtkParallelRenderManager::PreRenderProcessing | ( | ) | [protected, pure virtual] |
Here is a good place to handle processing of data before and after render.
Implemented in vtkCompositeRenderManager.
| virtual void vtkParallelRenderManager::PostRenderProcessing | ( | ) | [protected, pure virtual] |
Here is a good place to handle processing of data before and after render.
Implemented in vtkCompositeRenderManager.
| virtual void vtkParallelRenderManager::SetRenderWindowSize | ( | ) | [protected, virtual] |
Called in satellites to set the render window size to the current FullImageSize and ReducedImageSize (or vice versa).
| virtual void vtkParallelRenderManager::LocalComputeVisiblePropBounds | ( | vtkRenderer * | ren, | |
| double | bounds[6] | |||
| ) | [protected, virtual] |
Called by ComputeVisiblePropBoundsRMI to get the bounds of a local renderer. Override this method if the true bounds are different than those reported by the renderer.
| virtual void vtkParallelRenderManager::MagnifyReducedImage | ( | ) | [protected, virtual] |
When called, fills FullImage.
| virtual void vtkParallelRenderManager::WriteFullImage | ( | ) | [protected, virtual] |
Write the full image back to the RenderWindow.
| virtual void vtkParallelRenderManager::ReadReducedImage | ( | ) | [protected, virtual] |
Reads in the reduced image from the RenderWindow.
| virtual int vtkParallelRenderManager::LastRenderInFrontBuffer | ( | ) | [protected, virtual] |
Returns 1 if the RenderWindow's last image is in the front buffer, 0 if it is in the back.
| virtual int vtkParallelRenderManager::ChooseBuffer | ( | ) | [protected, virtual] |
Select buffer to read from / render into.
| virtual void vtkParallelRenderManager::SetRenderWindowPixelData | ( | vtkUnsignedCharArray * | pixels, | |
| const int | pixelDimensions[2] | |||
| ) | [protected, virtual] |
Sets the current render window's pixel data.
| virtual int vtkParallelRenderManager::ImageReduceRenderer | ( | vtkRenderer * | ) | [inline, protected, virtual] |
Returns true if the image for the given renderer should be rendered at a reduced size to be magnified later. This method always returns true, but subclasses may render some renderers at a reduced size, magnify them, and then render the other renderers at full resolution.
Definition at line 537 of file vtkParallelRenderManager.h.
Member Data Documentation
vtkRenderWindow* vtkParallelRenderManager::RenderWindow [protected] |
Definition at line 424 of file vtkParallelRenderManager.h.
Definition at line 425 of file vtkParallelRenderManager.h.
vtkRendererCollection* vtkParallelRenderManager::Renderers [protected] |
Definition at line 426 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::ForceRenderWindowSize [protected] |
Definition at line 430 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::ForcedRenderWindowSize[2] [protected] |
Definition at line 431 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::RootProcessId [protected] |
The "root" node's process id. This is the node which is listening for and propagating new render events from the RenderWindow. All processes on the controller must have the same value. This value must be set before SetRenderWindow method is called. In the constructor or the SetController methods are good places. By default this is set to 0.
Definition at line 439 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::ObservingRenderWindow [protected] |
Definition at line 441 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::ObservingAbort [protected] |
Definition at line 442 of file vtkParallelRenderManager.h.
unsigned long vtkParallelRenderManager::StartRenderTag [protected] |
Definition at line 444 of file vtkParallelRenderManager.h.
unsigned long vtkParallelRenderManager::EndRenderTag [protected] |
Definition at line 445 of file vtkParallelRenderManager.h.
unsigned long vtkParallelRenderManager::ResetCameraTag [protected] |
Definition at line 446 of file vtkParallelRenderManager.h.
unsigned long vtkParallelRenderManager::ResetCameraClippingRangeTag [protected] |
Definition at line 447 of file vtkParallelRenderManager.h.
unsigned long vtkParallelRenderManager::AbortRenderCheckTag [protected] |
Definition at line 448 of file vtkParallelRenderManager.h.
double vtkParallelRenderManager::ImageReductionFactor [protected] |
Definition at line 450 of file vtkParallelRenderManager.h.
double vtkParallelRenderManager::MaxImageReductionFactor [protected] |
Definition at line 451 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::AutoImageReductionFactor [protected] |
Definition at line 452 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::WriteBackImages [protected] |
Definition at line 454 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::MagnifyImages [protected] |
Definition at line 455 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::MagnifyImageMethod [protected] |
Definition at line 456 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::UseRGBA [protected] |
Definition at line 458 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::SynchronizeTileProperties [protected] |
Definition at line 459 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::FullImageSize[2] [protected] |
Definition at line 460 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::ReducedImageSize[2] [protected] |
Definition at line 461 of file vtkParallelRenderManager.h.
vtkUnsignedCharArray* vtkParallelRenderManager::FullImage [protected] |
Definition at line 463 of file vtkParallelRenderManager.h.
Definition at line 464 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::FullImageUpToDate [protected] |
Definition at line 466 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::ReducedImageUpToDate [protected] |
Definition at line 467 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::RenderWindowImageUpToDate [protected] |
Definition at line 468 of file vtkParallelRenderManager.h.
vtkDoubleArray* vtkParallelRenderManager::Viewports [protected] |
Definition at line 470 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::Lock [protected] |
Definition at line 472 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::ParallelRendering [protected] |
Definition at line 473 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::RenderEventPropagation [protected] |
Definition at line 474 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::UseCompositing [protected] |
Definition at line 475 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::SyncRenderWindowRenderers [protected] |
Definition at line 476 of file vtkParallelRenderManager.h.
vtkTimerLog* vtkParallelRenderManager::Timer [protected] |
Definition at line 478 of file vtkParallelRenderManager.h.
double vtkParallelRenderManager::RenderTime [protected] |
Definition at line 480 of file vtkParallelRenderManager.h.
double vtkParallelRenderManager::ImageProcessingTime [protected] |
Definition at line 481 of file vtkParallelRenderManager.h.
double vtkParallelRenderManager::AverageTimePerPixel [protected] |
Used by SetImageReductionFactorForUpdateRate to smooth transitions transitions between image reduction factors.
Definition at line 485 of file vtkParallelRenderManager.h.
const int vtkParallelRenderManager::WIN_INFO_INT_SIZE [static, protected] |
Definition at line 582 of file vtkParallelRenderManager.h.
const int vtkParallelRenderManager::WIN_INFO_DOUBLE_SIZE [static, protected] |
Definition at line 583 of file vtkParallelRenderManager.h.
const int vtkParallelRenderManager::REN_INFO_INT_SIZE [static, protected] |
Definition at line 584 of file vtkParallelRenderManager.h.
const int vtkParallelRenderManager::REN_INFO_DOUBLE_SIZE [static, protected] |
Definition at line 585 of file vtkParallelRenderManager.h.
const int vtkParallelRenderManager::LIGHT_INFO_DOUBLE_SIZE [static, protected] |
Definition at line 586 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::AddedRMIs [protected] |
Definition at line 589 of file vtkParallelRenderManager.h.
unsigned long vtkParallelRenderManager::RenderRMIId [protected] |
Definition at line 590 of file vtkParallelRenderManager.h.
unsigned long vtkParallelRenderManager::BoundsRMIId [protected] |
Definition at line 591 of file vtkParallelRenderManager.h.
int vtkParallelRenderManager::UseBackBuffer [protected] |
Definition at line 592 of file vtkParallelRenderManager.h.
The documentation for this class was generated from the following file:
- dox/Parallel/vtkParallelRenderManager.h
