vtkExecutionScheduler Class Reference
#include <vtkExecutionScheduler.h>
Detailed Description
Scheduling execution with thread/computing resources distributing.This is a class for balancing the computing resources throughout the network
- Events:
- vtkCommand::UpdateEvent
Definition at line 61 of file vtkExecutionScheduler.h.
Member Typedef Documentation
Constructor & Destructor Documentation
| vtkExecutionScheduler::vtkExecutionScheduler | ( | ) | [protected] |
| vtkExecutionScheduler::~vtkExecutionScheduler | ( | ) | [protected] |
Member Function Documentation
| static vtkExecutionScheduler* vtkExecutionScheduler::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkObject.
| virtual const char* vtkExecutionScheduler::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkObject.
| static int vtkExecutionScheduler::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkObject.
| virtual int vtkExecutionScheduler::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkObject.
| static vtkExecutionScheduler* vtkExecutionScheduler::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkObject.
| void vtkExecutionScheduler::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
| static vtkExecutionScheduler* vtkExecutionScheduler::GetGlobalScheduler | ( | ) | [static] |
Return the global instance of the scheduler
| static vtkInformationIntegerKey* vtkExecutionScheduler::TASK_PRIORITY | ( | ) | [static] |
Key to store the priority of a task
| void vtkExecutionScheduler::Schedule | ( | vtkExecutiveCollection * | execs, | |
| vtkInformation * | info | |||
| ) |
Put the current set of executives (modules) to the be scheduled given its dependency graph which will be used to compute the set topological orders
| void vtkExecutionScheduler::SchedulePropagate | ( | vtkExecutiveCollection * | execs, | |
| vtkInformation * | info | |||
| ) |
Put the current set of executives (modules) to the be scheduled given its dependency graph which will be used to compute the set topological orders. Then wait for their execution to be complete
| void vtkExecutionScheduler::WaitUntilDone | ( | vtkExecutiveCollection * | execs | ) |
Wait until the current set of executives (modules) have finished executing
| void vtkExecutionScheduler::WaitUntilReleased | ( | vtkExecutiveCollection * | execs | ) |
Wait until the current set of executives (modules) have their inputs released
| void vtkExecutionScheduler::WaitUntilAllDone | ( | ) |
Wait for all tasks to be done
| void vtkExecutionScheduler::WaitForTaskDone | ( | vtkExecutive * | exec | ) |
Wait for a task that is on the scheduling queue to be done. If the task is not there, this will return immediately. If the exec is NULL, any task that is done will trigger this the return
| void vtkExecutionScheduler::WaitForInputsReleased | ( | vtkExecutive * | exec | ) |
Similar to WaitForTaskDone but return whenever input connections of a task are released instead of done computing. But exec cannot be NULL.
| vtkThreadMessager* vtkExecutionScheduler::GetTaskDoneMessager | ( | vtkExecutive * | exec | ) |
Return the thread messager reserved for the given exec to notify when it is done
| vtkThreadMessager* vtkExecutionScheduler::GetInputsReleasedMessager | ( | vtkExecutive * | exec | ) |
Return the thread messager reserved for the given exec to notify when it releases its inputs
| vtkMutexLock* vtkExecutionScheduler::GetInputsReleasedLock | ( | vtkExecutive * | exec | ) |
Return the mutex lock reserved for the given exec to notify when it releases its inputs
| void vtkExecutionScheduler::ReleaseResources | ( | vtkExecutive * | exec | ) |
Release the resources that are being used by the given exec
| void vtkExecutionScheduler::ReacquireResources | ( | vtkExecutive * | exec | ) |
Re-acquire the resource released earlier by ReleaseResource
| void vtkExecutionScheduler::RescheduleNetwork | ( | vtkExecutive * | sink | ) |
Redistribute the thread resources over the network from a sink with a maximum resource
| void vtkExecutionScheduler::RescheduleFrom | ( | vtkExecutive * | sink, | |
| vtkComputingResources * | resources | |||
| ) |
Redistribute the thread resources from a sink given a certain amount of resource
Friends And Related Function Documentation
friend class implementation [friend] |
Definition at line 144 of file vtkExecutionScheduler.h.
| void* vtkExecutionScheduler_ScheduleThread | ( | void * | data | ) | [friend] |
The scheduling thread that is responsible for queueing up module execution in the right order
| void* vtkExecutionScheduler_ExecuteThread | ( | void * | data | ) | [friend] |
Execute thread function that is responsible for forking process for each module
Member Data Documentation
vtkComputingResources* vtkExecutionScheduler::Resources [protected] |
Definition at line 134 of file vtkExecutionScheduler.h.
vtkThreadMessager* vtkExecutionScheduler::ScheduleMessager [protected] |
Definition at line 135 of file vtkExecutionScheduler.h.
vtkThreadMessager* vtkExecutionScheduler::ResourceMessager [protected] |
Definition at line 136 of file vtkExecutionScheduler.h.
vtkMutexLock* vtkExecutionScheduler::ScheduleLock [protected] |
Definition at line 137 of file vtkExecutionScheduler.h.
vtkMultiThreader* vtkExecutionScheduler::ScheduleThreader [protected] |
Definition at line 138 of file vtkExecutionScheduler.h.
int vtkExecutionScheduler::ScheduleThreadId [protected] |
Definition at line 139 of file vtkExecutionScheduler.h.
implementation* const vtkExecutionScheduler::Implementation [protected] |
Definition at line 142 of file vtkExecutionScheduler.h.
The documentation for this class was generated from the following file:
- dox/Filtering/vtkExecutionScheduler.h
