vtkImageShrink3D Class Reference
#include <vtkImageShrink3D.h>
Detailed Description
Subsamples an image.vtkImageShrink3D shrinks an image by sub sampling on a uniform grid (integer multiples).
- Examples:
- vtkImageShrink3D (Examples)
- Tests:
- vtkImageShrink3D (Tests)
Definition at line 34 of file vtkImageShrink3D.h.
Public Types | |
| typedef vtkThreadedImageAlgorithm | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
| void | SetMean (int) |
| virtual int | GetMean () |
| virtual void | MeanOn () |
| virtual void | MeanOff () |
| void | SetMinimum (int) |
| virtual int | GetMinimum () |
| virtual void | MinimumOn () |
| virtual void | MinimumOff () |
| void | SetMaximum (int) |
| virtual int | GetMaximum () |
| virtual void | MaximumOn () |
| virtual void | MaximumOff () |
| void | SetMedian (int) |
| virtual int | GetMedian () |
| virtual void | MedianOn () |
| virtual void | MedianOff () |
| virtual void | SetShrinkFactors (int, int, int) |
| virtual void | SetShrinkFactors (int[3]) |
| virtual int * | GetShrinkFactors () |
| virtual void | GetShrinkFactors (int &, int &, int &) |
| virtual void | GetShrinkFactors (int[3]) |
| virtual void | SetShift (int, int, int) |
| virtual void | SetShift (int[3]) |
| virtual int * | GetShift () |
| virtual void | GetShift (int &, int &, int &) |
| virtual void | GetShift (int[3]) |
| void | SetAveraging (int) |
| int | GetAveraging () |
| virtual void | AveragingOn () |
| virtual void | AveragingOff () |
Static Public Member Functions | |
| static vtkImageShrink3D * | New () |
| static int | IsTypeOf (const char *type) |
| static vtkImageShrink3D * | SafeDownCast (vtkObject *o) |
Protected Member Functions | |
| vtkImageShrink3D () | |
| ~vtkImageShrink3D () | |
| virtual int | RequestInformation (vtkInformation *, vtkInformationVector **, vtkInformationVector *) |
| virtual int | RequestUpdateExtent (vtkInformation *, vtkInformationVector **, vtkInformationVector *) |
| void | ThreadedRequestData (vtkInformation *request, vtkInformationVector **inputVector, vtkInformationVector *outputVector, vtkImageData ***inData, vtkImageData **outData, int ext[6], int id) |
| void | InternalRequestUpdateExtent (int *inExt, int *outExt) |
Protected Attributes | |
| int | ShrinkFactors [3] |
| int | Shift [3] |
| int | Mean |
| int | Minimum |
| int | Maximum |
| int | Median |
Member Typedef Documentation
Constructor & Destructor Documentation
| vtkImageShrink3D::vtkImageShrink3D | ( | ) | [protected] |
| vtkImageShrink3D::~vtkImageShrink3D | ( | ) | [inline, protected] |
Definition at line 82 of file vtkImageShrink3D.h.
Member Function Documentation
| static vtkImageShrink3D* vtkImageShrink3D::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkAlgorithm.
| virtual const char* vtkImageShrink3D::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkThreadedImageAlgorithm.
| static int vtkImageShrink3D::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkThreadedImageAlgorithm.
| virtual int vtkImageShrink3D::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkThreadedImageAlgorithm.
| static vtkImageShrink3D* vtkImageShrink3D::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkThreadedImageAlgorithm.
| void vtkImageShrink3D::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkThreadedImageAlgorithm.
| virtual void vtkImageShrink3D::SetShrinkFactors | ( | int | , | |
| int | , | |||
| int | ||||
| ) | [virtual] |
Set/Get the shrink factors
| virtual void vtkImageShrink3D::SetShrinkFactors | ( | int | [3] | ) | [virtual] |
Set/Get the shrink factors
| virtual int* vtkImageShrink3D::GetShrinkFactors | ( | ) | [virtual] |
Set/Get the shrink factors
| virtual void vtkImageShrink3D::GetShrinkFactors | ( | int & | , | |
| int & | , | |||
| int & | ||||
| ) | [virtual] |
Set/Get the shrink factors
| virtual void vtkImageShrink3D::GetShrinkFactors | ( | int | [3] | ) | [virtual] |
Set/Get the shrink factors
| virtual void vtkImageShrink3D::SetShift | ( | int | , | |
| int | , | |||
| int | ||||
| ) | [virtual] |
Set/Get the pixel to use as origin.
| virtual void vtkImageShrink3D::SetShift | ( | int | [3] | ) | [virtual] |
Set/Get the pixel to use as origin.
| virtual int* vtkImageShrink3D::GetShift | ( | ) | [virtual] |
Set/Get the pixel to use as origin.
| virtual void vtkImageShrink3D::GetShift | ( | int & | , | |
| int & | , | |||
| int & | ||||
| ) | [virtual] |
Set/Get the pixel to use as origin.
| virtual void vtkImageShrink3D::GetShift | ( | int | [3] | ) | [virtual] |
Set/Get the pixel to use as origin.
| void vtkImageShrink3D::SetAveraging | ( | int | ) |
Choose Mean, Minimum, Maximum, Median or sub sampling. The neighborhood operations are not centered on the sampled pixel. This may cause a half pixel shift in your output image. You can changed "Shift" to get around this. vtkImageGaussianSmooth or vtkImageMean with strides.
| int vtkImageShrink3D::GetAveraging | ( | ) | [inline] |
Choose Mean, Minimum, Maximum, Median or sub sampling. The neighborhood operations are not centered on the sampled pixel. This may cause a half pixel shift in your output image. You can changed "Shift" to get around this. vtkImageGaussianSmooth or vtkImageMean with strides.
Definition at line 60 of file vtkImageShrink3D.h.
| virtual void vtkImageShrink3D::AveragingOn | ( | ) | [virtual] |
Choose Mean, Minimum, Maximum, Median or sub sampling. The neighborhood operations are not centered on the sampled pixel. This may cause a half pixel shift in your output image. You can changed "Shift" to get around this. vtkImageGaussianSmooth or vtkImageMean with strides.
| virtual void vtkImageShrink3D::AveragingOff | ( | ) | [virtual] |
Choose Mean, Minimum, Maximum, Median or sub sampling. The neighborhood operations are not centered on the sampled pixel. This may cause a half pixel shift in your output image. You can changed "Shift" to get around this. vtkImageGaussianSmooth or vtkImageMean with strides.
| void vtkImageShrink3D::SetMean | ( | int | ) |
| virtual int vtkImageShrink3D::GetMean | ( | ) | [virtual] |
| virtual void vtkImageShrink3D::MeanOn | ( | ) | [virtual] |
| virtual void vtkImageShrink3D::MeanOff | ( | ) | [virtual] |
| void vtkImageShrink3D::SetMinimum | ( | int | ) |
| virtual int vtkImageShrink3D::GetMinimum | ( | ) | [virtual] |
| virtual void vtkImageShrink3D::MinimumOn | ( | ) | [virtual] |
| virtual void vtkImageShrink3D::MinimumOff | ( | ) | [virtual] |
| void vtkImageShrink3D::SetMaximum | ( | int | ) |
| virtual int vtkImageShrink3D::GetMaximum | ( | ) | [virtual] |
| virtual void vtkImageShrink3D::MaximumOn | ( | ) | [virtual] |
| virtual void vtkImageShrink3D::MaximumOff | ( | ) | [virtual] |
| void vtkImageShrink3D::SetMedian | ( | int | ) |
| virtual int vtkImageShrink3D::GetMedian | ( | ) | [virtual] |
| virtual void vtkImageShrink3D::MedianOn | ( | ) | [virtual] |
| virtual void vtkImageShrink3D::MedianOff | ( | ) | [virtual] |
| virtual int vtkImageShrink3D::RequestInformation | ( | vtkInformation * | , | |
| vtkInformationVector ** | , | |||
| vtkInformationVector * | ||||
| ) | [protected, virtual] |
Reimplemented from vtkImageAlgorithm.
| virtual int vtkImageShrink3D::RequestUpdateExtent | ( | vtkInformation * | , | |
| vtkInformationVector ** | , | |||
| vtkInformationVector * | ||||
| ) | [protected, virtual] |
Reimplemented from vtkImageAlgorithm.
| void vtkImageShrink3D::ThreadedRequestData | ( | vtkInformation * | request, | |
| vtkInformationVector ** | inputVector, | |||
| vtkInformationVector * | outputVector, | |||
| vtkImageData *** | inData, | |||
| vtkImageData ** | outData, | |||
| int | extent[6], | |||
| int | threadId | |||
| ) | [protected, virtual] |
If the subclass does not define an Execute method, then the task will be broken up, multiple threads will be spawned, and each thread will call this method. It is public so that the thread functions can call this method.
Reimplemented from vtkThreadedImageAlgorithm.
| void vtkImageShrink3D::InternalRequestUpdateExtent | ( | int * | inExt, | |
| int * | outExt | |||
| ) | [protected] |
Member Data Documentation
int vtkImageShrink3D::ShrinkFactors[3] [protected] |
Definition at line 82 of file vtkImageShrink3D.h.
int vtkImageShrink3D::Shift[3] [protected] |
Definition at line 85 of file vtkImageShrink3D.h.
int vtkImageShrink3D::Mean [protected] |
Definition at line 86 of file vtkImageShrink3D.h.
int vtkImageShrink3D::Minimum [protected] |
Definition at line 87 of file vtkImageShrink3D.h.
int vtkImageShrink3D::Maximum [protected] |
Definition at line 88 of file vtkImageShrink3D.h.
int vtkImageShrink3D::Median [protected] |
Definition at line 89 of file vtkImageShrink3D.h.
The documentation for this class was generated from the following file:
- dox/Imaging/vtkImageShrink3D.h
