vtkOutlineCornerSource Class Reference
#include <vtkOutlineCornerSource.h>
Detailed Description
create wireframe outline corners around bounding boxvtkOutlineCornerSource creates wireframe outline corners around a user-specified bounding box.
Definition at line 27 of file vtkOutlineCornerSource.h.
Public Types | |
| typedef vtkOutlineSource | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
| virtual void | SetCornerFactor (double) |
| virtual double | GetCornerFactor () |
Static Public Member Functions | |
| static int | IsTypeOf (const char *type) |
| static vtkOutlineCornerSource * | SafeDownCast (vtkObject *o) |
| static vtkOutlineCornerSource * | New () |
Protected Member Functions | |
| vtkOutlineCornerSource () | |
| ~vtkOutlineCornerSource () | |
| int | RequestData (vtkInformation *, vtkInformationVector **, vtkInformationVector *) |
Protected Attributes | |
| double | CornerFactor |
Member Typedef Documentation
Constructor & Destructor Documentation
| vtkOutlineCornerSource::vtkOutlineCornerSource | ( | ) | [protected] |
| vtkOutlineCornerSource::~vtkOutlineCornerSource | ( | ) | [inline, protected] |
Definition at line 45 of file vtkOutlineCornerSource.h.
Member Function Documentation
| virtual const char* vtkOutlineCornerSource::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkOutlineSource.
| static int vtkOutlineCornerSource::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkOutlineSource.
| virtual int vtkOutlineCornerSource::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkOutlineSource.
| static vtkOutlineCornerSource* vtkOutlineCornerSource::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkOutlineSource.
| void vtkOutlineCornerSource::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkOutlineSource.
| static vtkOutlineCornerSource* vtkOutlineCornerSource::New | ( | ) | [static] |
Construct outline corner source with default corner factor = 0.2
Reimplemented from vtkOutlineSource.
| virtual void vtkOutlineCornerSource::SetCornerFactor | ( | double | ) | [virtual] |
Set/Get the factor that controls the relative size of the corners to the length of the corresponding bounds
| virtual double vtkOutlineCornerSource::GetCornerFactor | ( | ) | [virtual] |
Set/Get the factor that controls the relative size of the corners to the length of the corresponding bounds
| int vtkOutlineCornerSource::RequestData | ( | vtkInformation * | request, | |
| vtkInformationVector ** | inputVector, | |||
| vtkInformationVector * | outputVector | |||
| ) | [protected, virtual] |
This is called by the superclass. This is the method you should override.
Reimplemented from vtkOutlineSource.
Member Data Documentation
double vtkOutlineCornerSource::CornerFactor [protected] |
Definition at line 49 of file vtkOutlineCornerSource.h.
The documentation for this class was generated from the following file:
- dox/Graphics/vtkOutlineCornerSource.h
