vtkPLYReader Class Reference
#include <vtkPLYReader.h>
Detailed Description
read Stanford University PLY polygonal file formatvtkPLYReader is a source object that reads polygonal data in Stanford University PLY file format (see http://graphics.stanford.edu/data/3Dscanrep). It requires that the elements "vertex" and "face" are defined. The "vertex" element must have the properties "x", "y", and "z". The "face" element must have the property "vertex_indices" defined. Optionally, if the "face" element has the properties "intensity" and/or the triplet "red", "green", and "blue"; these are read and added as scalars to the output data.
- See also:
- vtkPLYWriter
- Tests:
- vtkPLYReader (Tests)
Definition at line 40 of file vtkPLYReader.h.
Public Types | |
| typedef vtkPolyDataAlgorithm | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
| virtual void | SetFileName (const char *) |
| virtual char * | GetFileName () |
Static Public Member Functions | |
| static int | IsTypeOf (const char *type) |
| static vtkPLYReader * | SafeDownCast (vtkObject *o) |
| static vtkPLYReader * | New () |
Protected Member Functions | |
| vtkPLYReader () | |
| ~vtkPLYReader () | |
| int | RequestData (vtkInformation *, vtkInformationVector **, vtkInformationVector *) |
Protected Attributes | |
| char * | FileName |
Member Typedef Documentation
Constructor & Destructor Documentation
| vtkPLYReader::vtkPLYReader | ( | ) | [protected] |
| vtkPLYReader::~vtkPLYReader | ( | ) | [protected] |
Member Function Documentation
| virtual const char* vtkPLYReader::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkPolyDataAlgorithm.
| static int vtkPLYReader::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkPolyDataAlgorithm.
| virtual int vtkPLYReader::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkPolyDataAlgorithm.
| static vtkPLYReader* vtkPLYReader::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkPolyDataAlgorithm.
| void vtkPLYReader::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkPolyDataAlgorithm.
| static vtkPLYReader* vtkPLYReader::New | ( | ) | [static] |
Construct object with merging set to true.
Reimplemented from vtkPolyDataAlgorithm.
| virtual void vtkPLYReader::SetFileName | ( | const char * | ) | [virtual] |
Specify file name of stereo lithography file.
| virtual char* vtkPLYReader::GetFileName | ( | ) | [virtual] |
Specify file name of stereo lithography file.
| int vtkPLYReader::RequestData | ( | vtkInformation * | request, | |
| vtkInformationVector ** | inputVector, | |||
| vtkInformationVector * | outputVector | |||
| ) | [protected, virtual] |
This is called by the superclass. This is the method you should override.
Reimplemented from vtkPolyDataAlgorithm.
Member Data Documentation
char* vtkPLYReader::FileName [protected] |
Definition at line 59 of file vtkPLYReader.h.
The documentation for this class was generated from the following file:
- dox/IO/vtkPLYReader.h
