vtkLookupTableItem Class Reference
#include <vtkLookupTableItem.h>
Detailed Description
Definition at line 26 of file vtkLookupTableItem.h.
Public Types | |
| typedef vtkScalarsToColorsItem | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| virtual void | PrintSelf (ostream &os, vtkIndent indent) |
| virtual void | GetBounds (double bounds[4]) |
| void | SetLookupTable (vtkLookupTable *t) |
| virtual vtkLookupTable * | GetLookupTable () |
Static Public Member Functions | |
| static vtkLookupTableItem * | New () |
| static int | IsTypeOf (const char *type) |
| static vtkLookupTableItem * | SafeDownCast (vtkObject *o) |
Protected Member Functions | |
| vtkLookupTableItem () | |
| virtual | ~vtkLookupTableItem () |
| virtual void | ComputeTexture () |
Protected Attributes | |
| vtkLookupTable * | LookupTable |
Member Typedef Documentation
Constructor & Destructor Documentation
| vtkLookupTableItem::vtkLookupTableItem | ( | ) | [protected] |
| virtual vtkLookupTableItem::~vtkLookupTableItem | ( | ) | [protected, virtual] |
Member Function Documentation
| static vtkLookupTableItem* vtkLookupTableItem::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkObject.
| virtual const char* vtkLookupTableItem::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkScalarsToColorsItem.
| static int vtkLookupTableItem::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkScalarsToColorsItem.
| virtual int vtkLookupTableItem::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkScalarsToColorsItem.
| static vtkLookupTableItem* vtkLookupTableItem::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkScalarsToColorsItem.
| virtual void vtkLookupTableItem::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkScalarsToColorsItem.
| virtual void vtkLookupTableItem::GetBounds | ( | double | bounds[4] | ) | [virtual] |
Bounds of the item, by default (0, 1, 0, 1) but it mainly depends on the range of the ScalarsToColors function. Need to be reimplemented by subclasses if the range is != [0,1]
Reimplemented from vtkScalarsToColorsItem.
| void vtkLookupTableItem::SetLookupTable | ( | vtkLookupTable * | t | ) |
| virtual vtkLookupTable* vtkLookupTableItem::GetLookupTable | ( | ) | [virtual] |
| virtual void vtkLookupTableItem::ComputeTexture | ( | ) | [protected, virtual] |
Need to be reimplemented by subclasses, ComputeTexture() is called at paint time if the texture is not up to date compared to vtkScalarsToColorsItem Return false if no texture is generated.
Implements vtkScalarsToColorsItem.
Member Data Documentation
vtkLookupTable* vtkLookupTableItem::LookupTable [protected] |
Definition at line 45 of file vtkLookupTableItem.h.
The documentation for this class was generated from the following file:
- dox/Charts/vtkLookupTableItem.h
